Fit for DANFOSS Danfoss Pressure Switch KP1 Controller(KP2)

Brand: Danfoss
Model KP1 KP2 KP36 KP5 KP35
Item No.:A005
Origin:India
Decoration and construction content
Installation Engineering:Material
Plastic: Color Classification
KP1,KP2,KP5,KP35,KP36,KP15 060-126566 Automatic, KP15 060-126466 Manual Ambient temperature: 40 - +65°C (+80°C for up to 2 hours).
DIN certified unit: 40 - +65°C (+80°C for up to 2 hours).
Maximum operating pressure = 17 bar
Max test pressure = 20 bar
Shock load, AC:
AC1: 16A, 400V
AC3: 16A, 400V
AC15: 10A, 400V
Maximum starting current (LR): 112 A, 400 V
Shock load, DC:
DC13: 12 W, 220 V control current



characteristic

value

Type KP1
Weight [kg] 0.336 [kg]
Ambient temperature [Celsius] -25 - 65 °C
Ambient temperature [Fahrenheit] -13 - 149 °F
Whether ammonia is used
Certification C UL US
Certification PED
Interface size 1/4 inch
Interface type bell mouth
Contact function SPDT
Contact capacity AC1=16 A, 400 V
Contact capacity AC15=10 A, 400 V
Contact capacity AC3=16 A, 400 V
Contact capacity DC13=12 W, 220 V
Contact capacity LR=112 A, 400 V
Differential pressure [bar] 0.7 - 4 bar
Differential [psi] 10.2 - 58 psi
Protection grade IP44
Same product 060-110166
Maximum test pressure [bar] 20 bar
Maximum operating pressure [bar] 17 bar
Maximum operating pressure [psig] 245 psig
Packaging formatMulti pack
Quantity per standard package 36 pcs
Adjustment Range [psig] 6 inHg - 108 psig
Adjustment range [bar] -0.2 - 7.5 bar

Various specifications are complete, including KP1 KP2 KP5 KP35 KP36 KP15
