US Stock ZAC 110V M12-M48 Electric Tapping Machine Flexible Arm Tapper with 50-200rpm Universal Tapping Machine, 13PCS ISO Collets Includes
$3,999.00
- Model: M48R( for M12-M48 universal Tapping), Universal Type, Supply Voltage: 220V/110V(send with a voltage transformer for free), Rated Power: 1200W, Rotated Speed: 50-250r/min
- Good at vertical and horizontal work of complex and heavy workpiece, locate quickly, and process accurately
- Manual, Automatic & Gap Modes, total 3 Modes of Working Mode for Your Option. Automatic mode can effectively control the depth of tapping, realize the blind tapping.
- Standard accessories: Tapping arm+servo motor and reducer+tap holder M12-M48(ISO full set)+Universal Joint
- Applicable materials: Aluminum, Copper, A3 Steel, 45 Steel, Cast Iron, Pig Iron, Q235, S136, Mold Steel, 718H, 40Cr, Stainless Steel and Other Metal Materials, Plastic and Wood and other Materials
This product is fulfilled by seller
Technical paramaters for M48R
(Universal tapping, Lifting function is newly added )
- Voltage: 220V (for US customer, will offer a voltage transformer for free to adapt the local 110V voltage)
- Taping Capacity: M12-M48 (Aluminum, Steel, Stainless steel)
- Power: 1200W
- Max. Rotating Speed: 0-50rpm(M12-M24 tapping) 0-250rpm(M30-M48 tapping) stepless speed regulation
- Working area: Horizontal: 1250mm
- Vertical: 400mm adjustable
Packing List (Packing Weight: 125kg, Standard Wooden Package)
- Tapping Arm(One set)
- Servo Motor and Reducer (One set)
- Tap Holder (ISO 13pcs: M12 M14 M16 M18-M20 M22 M24 Conversion chuck(45-31) M27-M30 M33 M36 M40 M42 M45-M48, if you need JIS/DIN tap holder, pls leave a note when ordering. Customization for tap holders is also accepted, pls PM us)
- Universal Joint (tapping in any angle)
Advantages
- Quality servo motor, strong output, enhanced reducer, gear durable, with intelligent torque protection.
- Advanced mechanical design, overall rigidity is strong, durable.
- Simple and flexible high definition touch screen; Program HD Human-machine Interface, adjusted forward and backward speed.
- Manual, Automatic & Gap Modes, total 3 Modes of Working Mode for Your Choice.
- Realize the vertical and horizontal work of complex and heavy workpiece, locate quickly, and process accurately.
- Automatic mode can effectively control the depth of tapping, realize the blind tapping besides through tapping.
| Brand Name | ZAC |
|---|---|
| Part Number | ZACL0308-A5Tapping |
| Wattage | 1200.000000 |
| Wattage Unit | Watts |
