Dixell XR04CX-5N0C1 230V/50-60Hz Digital Temperature Thermostat Controller Compressor Defrost Adjustable for Normal Low Temperature Ventilated Refrigerating Units(with 2pcs NTC Probe Sensors)

The XR04CX, in 32x74x50 mm short format, is microprocessor based controller suitable for applications on normal or low temperature refrigerating units. It provides two relay output: one for compressor and the other one for defrost. It provides two NTC probe inputs, one for room temperature and other one to control defrost termination. The instrument is fully configurable through special parameters that can be easily programmed through the keyboard or by the HOTKEY.

Specification
Producer: DIXELL
Type: XR04CX-5N0C1
Mounting Measurements: 71mm x 29mm
Built-in Depth: 56mm
Supply: 230V/50-60Hz
Voltage Type: AC
Probe Type: NTC
Number of Relay Outputs: 1
Relay Output 1: NO-20A(8)
Input: 1NTC
Kind of Protection: IP54
Version: Defrosting Function / Time Control
Measuring Range: -40°C up to +110°C
Display: 2.5 Digit

Defrost
Two defrost modes are available through the td parameter:
td=EL defrost through electrical heater (compressor OFF);
td=in hot gas defrost (compressor ON).
Other parameters are used to control the interval between defrost cycles (id), its maximum
length (Md) and two defrost modes: timed or controlled by the evaporator's probe. At the end
of defrost dripping time is started, its length is set in the dt parameter. With dt=0 the dripping time is disabled

Package Include
1 X Dixell XR02CX Digital Thermostat Controller
2 X Clips
2 X Black Temperature Probes
