Yoebor Stainless Steel 304 Compression Tube Fitting Straight Adapter Connector with Double Ferrules 1/4" OD x 1/4" NPT Male, Pack of 2
$8.99
- Adapter connects to tubing on one end and has an NPT male connector on the other, twin ferrule for a leak-resistant seal in high-pressure applications.
- Notice: “OD” is the size of the tube you will connect, not the size of the female compression. NPT is the size of the male thread, not the OD of the male thread.
- Material: 304 stainless steel , corrosion resistant ductility at high temperatures, and low magnetic permeability.
- Working Pressure: 0-20mpa | 0-2900psi; Working Temperature: -50- 450°C | -58～842°F
- Compression fitting just can be used for connecting hard tube, such as steel tube, copper tube, etc. If you want to connect hoses, you may need use it with a compression insert bush. Otherwise, it may cause leakage. Please ensure the cut of the connecting tube is flat, otherwise it may also cause leakage.
This product is fulfilled by seller
Pipe and tube fittings are components used for connecting, terminating, controlling flow, and changing the direction of piping in many different industries. Compression fittings do not require tools or sealants, and are useful in installations where a heat source, such as a soldering torch, is prohibited. When purchasing fittings, consider the application, as this will affect material type, shape, size, and required durability. Fittings are available threaded or unthreaded, in many shapes, styles, sizes, and schedules (pipe wall thickness).
Using the step
1.Cut the seamless steel tube with suitable length, the cut surface should be smooth and free of burrs
2.Put the nut and ferrule on the steel pipe in sequence, paying attention to the direction
3. Apply lubricating oil on ON the connector body and the ferrule, insert the steel pipe into the joint body to the end, and start to tighten the nut by hand
| Brand Name | Yoebor |
|---|---|
| Part Number | 00001 |
| Number of Pieces | 2 |
