VEVOR PTO Shaft, 1-3/8" 6 Spline Tractor and Implement Ends PTO Driveline Shaft, Series 4 Tractor PTO Shaft, 43"-59" Brush Hog PTO Shaft with Slip Clutch Black, for Finish Mower, Rotary Cutter
$0.00
- Sturdy and Durable: This PTO shaft is a well-forged series4 driveline shaft with CE certification. It consists of a slip clutch, a solid 20CrMnTi carburized steel universal joint and a Q345 steel tube inside the shield. The PTO shaft is durable and robust when working with various agricultural machinery.
- 6 Spline Ends: Tractor end: 1-3/8" x 6 Spline; implement end: 1-3/8" x 6 Spline. Our brush hog PTO shaft can match perfectly with the same size and type of implements and tractors, providing magnificent driving force for your machinery. Your machinery will be running like never before.
- Adjustable Length: Compressed Length: 43" / 1100 mm; Extended Overall Length: 59" / 1500 mm. The tiller PTO shaft is designed with a telescoping steel tube, a universal joint, and yokes. It has 35 Hp, 26 Kw, and 460 Nm torque at 540 rpm, while at 1000 rpm features 53 Hp, 39 Kw, and 360 Nm torque. It allows two sides of the PTO drive line shaft to spin at different speeds.
- Easy Assembly＆Safer Use: As a high-efficient power transmission tool, our PTO extender shaft can be easily assembled for effortless direct replacement. The security chain and sturdy shield eliminate potential dangers in the transmission process.
- Wide Application: The PTO (Power Take-Off) shaft transfers the power from the tractor to the PTO powered attachment. It is widely used on mowers, rotary tillers, brush cutters, hush hug, tractors, and many more. Control the speed and power of your machine effectively. Powerful torque conversion and reliability will leave you wishing you got our PTO shaft sooner.
This product is fulfilled by seller
key FeaturesHeavy-Duty PTO ShaftThis T4 tiller PTO shaft is made of high-quality 20CrMnTi carburized steel and Q345 tube steel, with a black-painted surface to strengthen its durability and stand large impacts, higher torque, and high-speed.1-3/8" Connection EndsFeaturing the 6-spline shaft end in tractor and implement ends, the tractor PTO link shaft can match with 1 3/8" PTO powered farm equipment or machinery. It stands out with superior power-transfer ability.43"-59" Stretchable LengthThe PTO extender has a flexible expending design with a compressed length: 43" / 1100 mm and an extended length: 59" / 1500 mm. At 540rpm with 35hp, 26Kw, and 460 nm torque; 53hp, 39Kw, and torque 360 nm at 1000rpm.Compact Transmit StructureThe PTO shaft is assembled in a compact structure, consisting of a telescoping tube, a universal joint, yokes, a plastic shield and chain for protection. It allows two speeds on both ends and transfers the power into the equipment.Simple & Quick InstallationThe PTO shaft for the bush hug with spline and round ends to attach implements and tractors quickly. If you want to cut it to the proper length, please read the manual carefully and remember to deburr the edges after cutting.Wide Range ApplicationThe PTO shaft, proving robust power force to the PTO powered attachment, is most commonly used on mowers, wood chippers, rotary tillers, rotary cutters, brush cutters, hush hug, tractors, etc.SpecificationsMaterial: 20CrMnTi Carburized Steel + Q345 Steel + PlasticTractor End: 1-3/8" x 6 SplineImplement End: 1-3/8" x 6 SplineCompressed Length: 43" / 1100 mmExtended Overall Length: 59" / 1500 mmPackage Content1 x PTO Shaft1 x Locking Pin1 x User Manual
| Brand Name | VEVOR |
|---|---|
| Part Number | 43”-59” Black PTO Shaft |
