MACHINIST X99 LGA 2011-V3 Motherboard, Intel 5th/6th Gen Computer Server Motherboard for Intel Xeon E5 V3/V4, Core i7 (Micro ATX, PCIe 3.0, Dual M.2 Slot, SATA 6Gb/s, DDR4 ECC)
$119.99
- LGA 2011-V3 Motherboard: Supports Intel Xeon E5 V3/V4 and Core 5th/6th I7 series processors on LGA 2011-V3 sockets (eg. Intel Xeon E5-2696 v3, E5-2666 v3, E5-2680 v3, E5-2630 V4, E5-2650 V4, E5-2680 V4, Intel Core i7-6950X etc.)
- 4-channel DDR4 Slots: This X99 motherboard has 4 memory slots, compatible with DDR4 ECC, RECC and Non-ECC memory. Support 2133/2400MHz memory clock speed, the maximum capacity is 128GB
- Dual M.2 Interfaces: The Intel LGA 2011-3 motherboard has two NVME M.2 interfaces. Both interfaces support PCIe Gen3x4, and each interface can provide an ultra-high transfer rate of 3600MB/s
- PCIe Expansion Slots: 1 PCIe 3.0 X16 graphics card slot (steel shell) and 1 PCIe 2.0 X1 slot. The PCle 3.0 protocol supports 8.0 GT/s, and the transmission rate of the X16 channel can reach 32Gb/s. The X1 slot can be used to expand the network card, sound card, and hard disk
- Server Chip: This gaming motherboard is equipped with C612 chip. The C612 chipset has rich scalability and reliability features to fully meet the needs of large-scale data processing and virtualization environments
- Package Includes: 1*LGA 2011-v3 cooler bracket, 1*SATA cable, 1*I/O shield, 1*motherboard. User manual is not included in the package and can be downloaded from product description page "Product guides and documents" if you need
- Warm Tips: If the placa madre has no display, , no boot, no screen, no network card, no sound card, etc., We can help you solve them. It is recommend driver download: Driver Talent, or use Win 10 system, it can help you solve all the driver problems
This product is fulfilled by seller
MACHINIST X99 K9 Motherboard for Intel Core i7 5th/6th and XEON E5 V3/V4 series CPUs on LGA 2011-3 Socket, M-ATX Computer Server Motherbaord
Common Problems:
1. The diagnostic card appears on the “FF” code, may be the CPU is incompatible, CPU pins on the foreign body or power supply is not properly connected. You can use an eraser to wipe the metal contact surface of the CPU to ensure cleanliness.
2. If the code “B7”, “B9”, “53”, “B0”, this is the motherboard did not Detect the memory problem. You can unplug the memory several times or use an eraser to wipe the metal contact surface of the memory to solve the problem.
3. The installation of Win 10 system can avoid a lot of unnecessary trouble, without having to download any drivers on their own to use the computer normally.
4. If you want to enter the BIOS, please press the “Del” key continuously after pressing the boot button. Please don't wait until the boot logo screen appears on the computer screen, because it's already too late.
X99 K9 Motherboard Specification:
Main chipset: Intel C612
Motherboard structure: Micro ATX
CPU socket: Intel LGA 2011-3 (Support Intel Core i7 5th/6th , XEON E5 V3/V4)
Memory slot: DDR4 (Support 2400/2133 MHz, ECC, RECC and Non-ECC)
Maximum memory: 128GB
PCIe slot: 1 * PCIe 3.0 X16 slot, 1 * PCIe 2.0 X1 slot.
Storage interface: 9 * SATA 3.0, 2 * NVME M.2
USB Port: Rear(4 * USB 3.0, 4 * USB 2.0), Front(1 * USB 3.0, 1 * USB 2.0)
Onboard LAN: 1 * Gigabit LAN Port, 1 * WIFI M.2 Slot
Power connector: 24pin + 8pin DC
Power Supply: 8-layer PCB
Motherboard size: 235mm x 200mm
Package list:
1 * motherboard
1 * SATA cable
1 * LGA2011-3 CPU cooler bracket
1 * I/O shield
Common Problems:
1. The diagnostic card appears on the “FF” code, may be the CPU is incompatible, CPU pins on the foreign body or power supply is not properly connected. You can use an eraser to wipe the metal contact surface of the CPU to ensure cleanliness.
2. If the code “B7”, “B9”, “53”, “B0”, this is the motherboard did not Detect the memory problem. You can unplug the memory several times or use an eraser to wipe the metal contact surface of the memory to solve the problem.
3. The installation of Win 10 system can avoid a lot of unnecessary trouble, without having to download any drivers on their own to use the computer normally.
4. If you want to enter the BIOS, please press the “Del” key continuously after pressing the boot button. Please don't wait until the boot logo screen appears on the computer screen, because it's already too late.
X99 K9 Motherboard Specification:
Main chipset: Intel C612
Motherboard structure: Micro ATX
CPU socket: Intel LGA 2011-3 (Support Intel Core i7 5th/6th , XEON E5 V3/V4)
Memory slot: DDR4 (Support 2400/2133 MHz, ECC, RECC and Non-ECC)
Maximum memory: 128GB
PCIe slot: 1 * PCIe 3.0 X16 slot, 1 * PCIe 2.0 X1 slot.
Storage interface: 9 * SATA 3.0, 2 * NVME M.2
USB Port: Rear(4 * USB 3.0, 4 * USB 2.0), Front(1 * USB 3.0, 1 * USB 2.0)
Onboard LAN: 1 * Gigabit LAN Port, 1 * WIFI M.2 Slot
Power connector: 24pin + 8pin DC
Power Supply: 8-layer PCB
Motherboard size: 235mm x 200mm
Package list:
1 * motherboard
1 * SATA cable
1 * LGA2011-3 CPU cooler bracket
1 * I/O shield
| Brand Name | MACHINIST |
|---|---|
| Part Number | 00001 |
| Platform | Windows |
| Compatible Processors |
|
| Memory Storage Capacity Unit | GB |
| Memory Storage Capacity | 128.000000 |
| Memory Clock Speed | 2400.000000 |
| Memory Clock Speed Unit | MHz |
| RAM Memory Maximum Size Unit | GB |
| RAM Memory Maximum Size | 128.000000 |
| Total PCIe Ports | 2 |
