Fafeicy LCD Module, TFT Touch Screen Display Serial Peripheral Interface ILI9488 HD 480x320 3.5in (1 PCS)
$19.53
- With optional touch function: This LCD Module possess 480×320 HD resolution with optional touch function
- Serial peripheral interface bus: Using serial peripheral interface bus, only need a few IO to light up the screen display
- Memory card slot: Equipped with for memory card slot for easy expansion of experiments, providing a wealth of sample programs
- Practical: This multifunctional LCD module can be used for other display functions through the transmission line
- Energy save: Compatible with 3.3V~5V operating voltage, which can realise low energy consumption to save electricity
This product is fulfilled by seller
Specification:
Item Type: LCD module
Size: 3.5in
Type: TFT
Driver Chip: ILI9488
Resolution: 480x320(Pixel)
Module Interface: 4-Wire serial peripheral interface
Effective Display Area(AA area): Approx. 49 x 73.4mm / 1.9 x 2.9in
Size of for PCB Bottom Plate: Approx. 56.3 x 98mm / 2.2 x 3.9in
VCC Power Supply Voltage: 3.3V~5V
Logic I/O Voltage: 3.3VTTL)
Package List:
1 x LCD Module
1 x Touch Pen
Note:
Please note that the new type and old type of this product will be sent randomly and make sure you will not mind before ordering.
Item Type: LCD module
Size: 3.5in
Type: TFT
Driver Chip: ILI9488
Resolution: 480x320(Pixel)
Module Interface: 4-Wire serial peripheral interface
Effective Display Area(AA area): Approx. 49 x 73.4mm / 1.9 x 2.9in
Size of for PCB Bottom Plate: Approx. 56.3 x 98mm / 2.2 x 3.9in
VCC Power Supply Voltage: 3.3V~5V
Logic I/O Voltage: 3.3VTTL)
Package List:
1 x LCD Module
1 x Touch Pen
Note:
Please note that the new type and old type of this product will be sent randomly and make sure you will not mind before ordering.
| Brand Name | Fafeicy |
|---|---|
| Part Number | Fafeicya1846psrzg |
| Is the item dishwasher safe? | No |
| Voltage Unit | Volts |
