KACOME Cable Pulling Mechanism Industrial Version BSL-MA130-20 for servo Flanges with 6 mm Axes Measuring Range 0-20 m
$1,778.40
- Operation:Simple and convenient operation
- Volume: Compact, sturdy structure, easy to install
- Savings: Cost-effective and cost-saving for customers.
- Protection: Displacement sensors also play an important role in safety protection.
- Equipment status: Displacement sensors can check the operating status of the equipment.
This product is fulfilled by seller
Produkte
Cable Pulling Mechanisms
Brief description
for servo flanges with
6 mm shaft, measuring range 0 m ... 10 m
Measuring lengths up to
0 m ... 10 meters
Repeatability
1 mm
Linearity
± 6 mm
Hysteresis
4 mm
Weight
5.8 kg (without encoder)
Material (rope)
Highly elastic 316 stainless steel
Cord
Spring sleeve material
Plastic
Housing material
Aluminum (anodized
coating treatment), die-cast zinc
Roller circumference
333 mm
Retraction spring force
10 N ... 20
N1)
Diameter (rope)
1.2 mm
Acceleration
40 m/s²
Adjustment speed
8 m/s
Resolution
To determine the system resolution,
Use the following :
Cable pull-out length per revolution / steps per revolution
Steps per revolution = resolution of the cable pull encoder combination
Operating temperature
30 °C ... +70 °C
Housing IP protection class
IP64
Lifetime
Typical 5000,000 cycles2)3)
Model Number : BSL-MA130
Measuring length up to : 0 m-20m
Circumference of drum : 333mm
Material of rope : Highly flexible 316 stainless steel rope
Spring sleeve material : plastic
Casing material : Aluminum (anode coating treatment), die-cast zinc
Cable Pulling Mechanisms
Brief description
for servo flanges with
6 mm shaft, measuring range 0 m ... 10 m
Measuring lengths up to
0 m ... 10 meters
Repeatability
1 mm
Linearity
± 6 mm
Hysteresis
4 mm
Weight
5.8 kg (without encoder)
Material (rope)
Highly elastic 316 stainless steel
Cord
Spring sleeve material
Plastic
Housing material
Aluminum (anodized
coating treatment), die-cast zinc
Roller circumference
333 mm
Retraction spring force
10 N ... 20
N1)
Diameter (rope)
1.2 mm
Acceleration
40 m/s²
Adjustment speed
8 m/s
Resolution
To determine the system resolution,
Use the following :
Cable pull-out length per revolution / steps per revolution
Steps per revolution = resolution of the cable pull encoder combination
Operating temperature
30 °C ... +70 °C
Housing IP protection class
IP64
Lifetime
Typical 5000,000 cycles2)3)
Model Number : BSL-MA130
Measuring length up to : 0 m-20m
Circumference of drum : 333mm
Material of rope : Highly flexible 316 stainless steel rope
Spring sleeve material : plastic
Casing material : Aluminum (anode coating treatment), die-cast zinc
| Brand Name | KACOME |
|---|---|
| Part Number | KACOME |
