0XA Wedge Type Quick Change Tool Post Set For Mini Lathe 6-9" SWING Steel Material
- Perfect for 7 x 10", 7 x 12", 7 x 14" mini lathe
- Tool Post and Tool Holders No. 1, No. 2, No. 4, No. 7, No. 10
- Advanced design provides built in quick tool changing versatility with positive rigidity to meet the most exacting working tolerances
- No time wasted with shims
- Wedge type tool posts are precision engineered to assure repetitive accuracy
Tool Post and Tool Holders No. 1, No. 2, No. 4, No. 7, No. 10
No. 1 Turning & Tool Holder
No. 2 Boring, Turning & Facing Tool Holder
No. 4 Boring Bar Tool Holder
No. 7 Universal Parting Blade Tool Holder
No. 10 Knurling, Facing & Turning Tool Holder
The tool post bottom plate size is 44x40x8mm
Stud size is M10 and is perfect for most mini lathes, although modification may be needed for some machines (a bushing or new center stud for a smaller hole may be necessary) Slash Your Setup Time- instant changing from one operation to another
Whole set includes one each of:
- 250-000 Wedge Type Tool Post
- 250-001 Turning Tool Holder 250-0002 Boring, Turning Tool Holder
- 250-004 Heavy Duty Boring Bar Holder, can use two sizes boring bar 3/8" & 1/2"
- 250-007 Parting Blade Tool Holder, use 1/2" high parting blades
- 250-010 Knurling and Turning Tool Holder
The quick change tool post is a main accessory of the machine tool, it is consist of tool post and many kinds of tool holders, according to the processing requirements of the workpieces, correspording tool holders are selected to finish cylindrical facing, end facing, cutting, drilling, reaming, boring as well as other processing. It realizes to mount tool outside the machine tool, it has exchange tool quickly, high precision, rigidity strong etc. It is satisfactory accessories in place of square turrets
| Brand Name | LLDSIMEX |
|---|---|
| Part Number | LLDS-120-140 |
