PF10000471794
In stock
Alinan 3pcs TEC1-12704 Semiconductor Refrigeration Tablets TEC1-12704 12V 4A Heatsink Thermoelectric Cooler Cooling Peltier Plate Module 40x40MM
$16.99
- 【Model】: TEC1-12704
- 【Dimensions】: 40 * 40 * 3.4mm
- 【Cooling Power】: Qcmax 24W
- ★It can be used for numerous applications from CPU coolers to alternate power sources, or even for your own custom car drink warmer/cooler.
- ★Heat sink or water-cooled heat sink must be installed on the surface of the cooling peltier plate, otherwise it will burn out.
This product is fulfilled by seller
Feature:
Model: TEC1-12704
Dimensions: 40 * 40 * 3.4mm
Components Logarithmic: 127
Maximum Temperature: Tmax (Qc = 0) 60 ℃
Operating Current: Imax = 12 (rated voltage startup)
Rated Voltage: DC12V (Vmax: 15.5V)
Cooling Power: Qcmax 24W
Assembly Pressure: 85N/cm2
Working Environment: Temperature range -55 ℃ --83 ℃ (high ambient temperature will directly affect the cooling efficiency)
Storage Conditions: -40 -60 ℃
Model: TEC1-12704
Dimensions: 40 * 40 * 3.4mm
Components Logarithmic: 127
Maximum Temperature: Tmax (Qc = 0) 60 ℃
Operating Current: Imax = 12 (rated voltage startup)
Rated Voltage: DC12V (Vmax: 15.5V)
Cooling Power: Qcmax 24W
Assembly Pressure: 85N/cm2
Working Environment: Temperature range -55 ℃ --83 ℃ (high ambient temperature will directly affect the cooling efficiency)
Storage Conditions: -40 -60 ℃
| Brand Name | Alinan |
|---|---|
| Part Number | Alinan |
| Cooler Heatsink Compatibility | CPU coolers (specific details not provided) |
| Item Height Unit | Inches |
| Item Height base to top | 0.130000 |
| Item Length Unit | Inches |
| Item Length Longer Edge | 1.570000 |
| Item Width Unit | Inches |
| Item Width Shorter Edge | 1.570000 |
