10 Ton Hydraulic Jack Single-Acting Mini Jack Ram with CP-180 Hydraulic Hand Pump, Stroke 1.97"
- [Large Load Tonnage] This manual hydraulic jack is made of high-quality steel for durability and it has a load tonnage of 10T. You can easily jack up heavier items by simply pressing the pump handle.
- [High Safety] The no-slip circle on the spindle can ensure that the items placed are more stable. The stop ring can prevent the jack from breaking and damaging when the load is applied. All of these provide a high degree of safety when using them so that you can use them with more confidence.
- [Leak-proof & Dust-proof] The jacks have threaded ZG3/8 fittings with steel balls to prevent reverse oil leakage. The interface dust cover also prevents the entry of impurities and dust. This extends the life of the jack.
- [Multi-angle Use] Vertical, horizontal or inverted placement orientation can be selected according to space requirements, but cannot be tilted use. In order to operate correctly, all cylinders need to be connected to a solid flat lifting surface rather than soft or rough surface.
- [Wide Application] This hydraulic porta power ram and hydraulic hand pump are often used in power, chemical, steel, bridges and other industries. and it is suitable for railway vehicle maintenance, mechanical installation, construction engineering support, etc.
10 Ton Hydraulic Jack Single-Acting Mini Jack Ram with CP-180 Hydraulic Hand Pump, Stroke 1.97"
This manual hydraulic jack is made of high-quality steel, which is strong and durable and not easy to deform. It has a load tonnage of 10T/22.46.22 lbs.
You can easily jack up heavier items by simply pressing the pump handle.
Specifications:
Color: Yellow+Black
Jack Model: RSC-1050
Pump Model: CP-180
Product Material: Steel
Oil Pipe Material: Rubber
Surface Treatment: Spraying
Spindle Surface Treatment: Chrome Plated
Jack Load Tonnage: 10T
Jack Stroke: 1.97"
Jack Body Height: 4.02"
Jack Extended Height: 5.98"
Jack Size: 5.6*3*4"in
Jack Oil Storage Capacity: 72cc
Jack Weight: 5.51 lbs
Pump Max Pressure: 70 MPa
Pump Weight: 6.61 lbs
Gross Weight:14.33 lbs
Details
Stop Ring: There is a stop ring under the spindle that can play a protective role when the spindle is raised to prevent breakage and damage. It is safer for you to use it.
On/Off Knob: There is a knob on the pump head for controlling the jack. Tune it to OFF to lift the jack. When tuned to ON, the jack will restart. This knob can make the operation more convenient and safer.
How to Use
1. Open the interface cover of the jack to connect with the pump's oil pipe interface and tighten the screw.
2. Turn the knob of the pump to OFF.
3. Place the jack under the object to be lifted and press the pump handle up and down to start working.
4. After the object is lifted, turn the knob to ON, and the jack will restart.
Package Included
1* Hydraulic Jack
1* Pump
1* Oil Pipe
Notes
1. Please use this item on hard and flat ground.
2. Please do not exceed the load capacity of the jack.
3. Please stop immediately when you see the stop line.
| Brand Name | Yoltckde |
|---|---|
| Part Number | RSC-1050/CP-180 |
| Load Capacity | 10.0 |
