Hantek Laptop PC USB Digital Storage Virtual Oscilloscope 2 Channels 20Mhz Handheld Portable Osciloscopio (6022BE)

Be the first to review this product

$65.90

Any Win10 driver issue, please kindly contact us via Amazon, we will support you to download and install it;
High performance, 48MSa/s real-time sampling, 20MHz bandwidth.Great industrial design, the high quality anodized aluminum case is extremely durable and heat-resistant.
2 channels 20MHz USB oscilloscope with USB2.0 PORT - there is no need extra power supply for the portable oscilloscope, it can be connected to pc through the USB port for power directly, similar interface with desktop oscilloscope, easy to use;
23 measurement functions, PASS/FAIL Check, be suitable for technical application.
POWFUL FUNCTION WITH SMALL SIZE - the usb oscilloscope owns ore than 20 kinds of automatic measurement functions, PASS/FAIL Check function, suitable for technical application,supports Windows 11, Windows 10, Windows 8, Windows 7, Windows NT, Windows XP, VISTA.

This product is fulfilled by seller

Skip to the beginning of the images gallery

Details

More Information

Reviews

Questions

Key Features
Hantek 6022BE20Mhz USB Digital Storage Oscilloscope
2 Channels
20MHz Bandwidth
20mV-5V Gain range
2 PP80 passive probes
48MS/s Max. Sample rate
1MΩ 25pF Input Impedance
Trigger Mode: Auto, Normal and Single
Trigger Type: Rising edge, falling edge
Math: FFT, addition, subtraction, multiplication, division.
Waveform Display:port/line, waveform average, persistence, intensity
Model:Hantek6022BE
Channel:2 Channels
Bandwidth:20MHz
Input Impedance:1MΩ 25pF
Max. Sample rate:48MS/s
Coupling:DC
Vertical resolution:8Bit
Gain range:20mV-5V
DC accuracy:±3%
Timebase range:4ns-5ks
Vertical adjustable:Yes
Input protection:Diode clamping
X-Y:Yes
EXT. Input:No
Trigger Mode:Auto, Normal and Single
Trigger Slope:+/-
Trigger level adjustable:Yes
Trigger Type:Rising edge, falling edge
Trigger Source:CH1, CH2
Pre/Post trigger:0-100%
Buffer size:1M
Sampling selection:Yes
Waveform Display:port/line, waveform average, persistence, intensity
Network:Open/Close
Vertical mode:CH1, CH2, Dual, ADD
Cursor measurement:Yes
Math:FFT, addition, subtraction, multiplication, division.
Cursor:Frequency, Voltage
Accessories:S/W CD, probes, manual, USB cord

More Information
Brand Name	Hantek
Part Number	6000BE
