uxcell KSD301 Thermostat 230°C/446°F 10A Normal Closed N.C Adjust Snap Disc Temperature Switch for Microwave,Oven,Coffee Maker 2pcs,Ceramic Material
$10.39
- Type: KSD301 230 degrees Celsius Thermal Control Switch 110V/120V/250V 10A NC (Normal Close), 6.3mm pin
- Normally Closed: The original state of temperature control switch contact is closed, and open when the temperature sensing exceeds the rated temperature 230 Celsius degree
- Advantage: Double metal chip, speed dynamic type, sensitive, reliable, stable action temperature, long service life, no arc phenomenon.
- Easy to installation : The flange on the switch is float and easy to installation.The pin width is 6.3mm
- Application: Mainly used for microwave,oven,coffee maker,Speed Cook oven,heater,Dryer,gas furnace,Bath Vent/Heater,wall heater,motor electric heating water dispenser, water bottles, coffee shell, electric iron, dryer, air conditioning, water heater, electronic cooker, heater, motor cleaner
This product is fulfilled by seller
Specification:
Product Name : Temperature Control Switch
Model: KSD301
Action Temperature: 230°C
Action Type: N.C (Normally Closed)
Rated Voltage/Current : 110V/120V/250V 10A
Pin Width : 6.3mm/0.25inch
Contact Life: More than 50,000 times (action times)
Electrical Strength: AC50Hz, 2000V/min no breakdown and arc phenomenon
Package Content :
2pcs x Temperature Control Switch
Description :
1.Normally Closed: The original state of temperature control switch contact is closed, and open when the temperature sensing exceeds the rated temperature.
2.Feature: Double metal chip, speed dynamic type, sensitive, reliable, stable action temperature, long service life, no arc phenomenon.
3.Advantage: General purpose, automatic reset, low cost, large capacity, minute current thermostats.
4.Application: Mainly used for microwave,oven,coffee maker,Speed Cook oven,heater,Dryer,gas furnace,Bath Vent/Heater,wall heater,motor electric heating water dispenser, water bottles, coffee shell, electric iron, dryer, air conditioning, water heater, electronic cooker, heater, motor cleaner
Product Name : Temperature Control Switch
Model: KSD301
Action Temperature: 230°C
Action Type: N.C (Normally Closed)
Rated Voltage/Current : 110V/120V/250V 10A
Pin Width : 6.3mm/0.25inch
Contact Life: More than 50,000 times (action times)
Electrical Strength: AC50Hz, 2000V/min no breakdown and arc phenomenon
Package Content :
2pcs x Temperature Control Switch
Description :
1.Normally Closed: The original state of temperature control switch contact is closed, and open when the temperature sensing exceeds the rated temperature.
2.Feature: Double metal chip, speed dynamic type, sensitive, reliable, stable action temperature, long service life, no arc phenomenon.
3.Advantage: General purpose, automatic reset, low cost, large capacity, minute current thermostats.
4.Application: Mainly used for microwave,oven,coffee maker,Speed Cook oven,heater,Dryer,gas furnace,Bath Vent/Heater,wall heater,motor electric heating water dispenser, water bottles, coffee shell, electric iron, dryer, air conditioning, water heater, electronic cooker, heater, motor cleaner
| Brand Name | uxcell |
|---|---|
| Part Number | a18110700ux0402 |
| Is the item dishwasher safe? | No |
| California Proposition 65 Warning Type | Chemical |
