SoloGood HOBBYEAGLE A3 Super 4 RC Plane Airplane Gyro Flight Controller Stabilizer for RC Fixed-Wing Airplane Model Plane FPV
- A3 Super 4 Gyro flight control is designed for fixed wing RC Airplane, 32-bit processor, high-precision 6-axis MEMS sensor, perfect hardware design and stable firmware, providing more reliable performance
- 6 flight modes and 6-stage mode switching, including gyro off mode, normal stabilization mode, lock mode, angle mode, balance mode and hoist mode
- Full support for PWM, PPM and multi-protocol digital serial receivers
- Flexible configurable output interface, providing 2 direct output channels
- Dual ailerons, dual lift systems, built-in flying wing (delta wing) and V-tail mixing
A3 Super 4 is a high-performance, powerful 6-axis gyroscope and balancer specially designed for model aircraft fixed-wing. On the basis of the previous generation, the hardware design is further improved, and the full support for multi-protocol digital serial receivers and the addition of customizable output interfaces make it more user-friendly and more reliable in use.
Remote overall gain adjustment;
Firmware can be upgraded, support setting card parameter adjustment
compatible with FrSky SBus, JETI SBus, RadioLink SBus and WFLY WBus
Spektrum DSM2/X 1024 Satellite Receiver
Spektrum DSM2/X 2048 Satellite Receiver
Spektrum SRXL
Multiplex SRXL / JR XBUS Mode B
Graupner SUMD
FlySky iBus
JETI EXBus
specifications：
Main controller: 32-bit microprocessor
Built-in sensors: High-precision MEMS 6-axis sensor
Gyro range: ± 2000 dps
Acceleration range: ± 4g
PWM output: 800 ~ 2220uS, median 1500/1520uS, frequency 50Hz ~ 333Hz
Working voltage:DC 4.8V ~ 8.4V
Working temperature: -10℃ ~ 50℃
Dimensions: 43×27×14mm (L×W×H)
Weight: 10g (without connecting cable)
Package Included:
1 x A3 Super 4 Main Controller
1×LED module
3 x Receiver Cable
1 x Data Cable
1 x Adapter
2 x Double-sided Tapes
| Brand Name | SoloGood |
|---|---|
| Part Number | SoloGood |
| Target Gender | Unisex |
| Manufacturer Minimum Age (MONTHS) | 16.000000 |
