PF10000461576
In stock
YUCHENGTECH AE500S-P Lab High Shear Dispersion Control Type Emulsifying Machine Emulsifying Mixer High Speed Mixing Homogenizer Homogenizing Emulsifier 40L (Water) 220-240V (Host+70G working head)
$1,599.00
- 1.Driven by a compact series excitation micro high-speed motor, it is suitable for mixing low to medium and high viscosity liquids in laboratory or pilot plant, and shearing emulsifying granular materials in liquid medium.
- 2.It has overload protection function, speed memory function, can set speed in advance, and can be suspended at any time. Easy to operate, superior performance and low noise.
- 3.The machine is composed of high speed motor, shear emulsifying head and speed control controller. The main engine adopts high quality engineering plastics and die - casting aluminum alloy as the body.
- 4.The working head is refined with high quality stainless steel, demountable, convenient for replacement, cleaning and sterilization.The working head is refined with high quality stainless steel, demountable, convenient for replacement, cleaning and sterilization.
- 5.The fuselage is all made of high quality engineering plastics, which ensures the safety and reliability in use.
This product is fulfilled by seller
Working principle
The experimental equipment is driven by a high-speed motor shearing emulsification head, which promotes high-speed circular motion of the rotor.
Intensive and reciprocating effects of hydraulic shear, friction, centrifugal extrusion and fluid-flow collision are formed in a reasonably narrow gap.
The experimental material circulates in the container to and fro over the working process, and withstands tens of thousands of shearing, tearing, impact and mixing times per minute,
so as to achieve the shear emulsification effect. Its efficiency is about one thousand times higher than that of ordinary stirring.
Parameters:
Rated voltage: AC220 V
Rated frequency: 50/60 Hz
Input power: 850 W
Output power: 500 W
Rated Torque: 34.1 N.cm
Working mode: S1 (continuous)
Operation control mode: combined control knob
Speed regulation range: 2000-14000 rpm
Speed Control Type: Stepless
Running Dynamic Display: Indicator Bar LED
Maximum Torque of Working Head: 34.0 N.cm
Maximum linear speed of rotor: 20.5 m/s
Material of working head: stainless steel 304
Diameter of working head: 70 mm
Minimum/maximum immersion height of working head: 50/236 mm
Stator standard configuration: 5 mm2 20 mm2 50 mm2
Processing capacity (H2O): 500-40000 ml
Maximum treatment viscosity: 8000 mPa.s
Permissible ambient temperature: not more than 40℃
Permissible relative humidity: not more than 80%
Shape size of the whole machine: 215 x 310 x 720 mm
Whole machine weight: 9.2 kg (gross weight: 11.0 kg)
The experimental equipment is driven by a high-speed motor shearing emulsification head, which promotes high-speed circular motion of the rotor.
Intensive and reciprocating effects of hydraulic shear, friction, centrifugal extrusion and fluid-flow collision are formed in a reasonably narrow gap.
The experimental material circulates in the container to and fro over the working process, and withstands tens of thousands of shearing, tearing, impact and mixing times per minute,
so as to achieve the shear emulsification effect. Its efficiency is about one thousand times higher than that of ordinary stirring.
Parameters:
Rated voltage: AC220 V
Rated frequency: 50/60 Hz
Input power: 850 W
Output power: 500 W
Rated Torque: 34.1 N.cm
Working mode: S1 (continuous)
Operation control mode: combined control knob
Speed regulation range: 2000-14000 rpm
Speed Control Type: Stepless
Running Dynamic Display: Indicator Bar LED
Maximum Torque of Working Head: 34.0 N.cm
Maximum linear speed of rotor: 20.5 m/s
Material of working head: stainless steel 304
Diameter of working head: 70 mm
Minimum/maximum immersion height of working head: 50/236 mm
Stator standard configuration: 5 mm2 20 mm2 50 mm2
Processing capacity (H2O): 500-40000 ml
Maximum treatment viscosity: 8000 mPa.s
Permissible ambient temperature: not more than 40℃
Permissible relative humidity: not more than 80%
Shape size of the whole machine: 215 x 310 x 720 mm
Whole machine weight: 9.2 kg (gross weight: 11.0 kg)
| Brand Name | YUCHENGTECH |
|---|---|
| Part Number | YUCHENGTECH |
