Motor LED Tacho, DC 8-24V 40mA 10-9999RPM 4 Digital LED Tachometer RPM Speed Meter with Hall Proximity Switch Sensor NPN Green for Industrial
$20.79
- IMPRESSIVE FEATURES: This digital tachometer is characterized by high , , stable and reliable. This digital tachometer can be applicable to various applications of RPM speed measurement.
- LCD DISPLAY: The digital tachometer has 0.56inch 4-digit LED screen display clear RPM readings in green. Which gives you a better visual experience and easier reading.
- WIDE APPLICATION: 8-24V wide power supply voltage, suitable for various applications of RPM speed measurement.
- HALL SENSOR: Comes with 3-wire NPN Hall proximity switch sensor.
- 100% SATISFACTION SERVICE: The Hall switch and the motor need to be fixed with brackets. The more stable the fixing, the more conducive to stable detection.
This product is fulfilled by seller
Specification:
Item Type: Tachometer
Operating Voltage: DC 8-24V, 40mA
Display: 0.56inch green LED, 4 digit reading
Measuring Range: 10-9999rpm
Measuring Accuracy: ±0.1%, reading±1digit
Display Refresh Rate: >3 times/sec
Overrange Display: Display 1 or -1 in the first digit position, none in the last three digit positions
Hall Proximity Switch Type: NPN NO
Tachometer Size: 79x26x43mm / 3.11x1.02x1.69in
Package List:
1 x LED Tachometer
1 x Hall Proximity Switch
1 x Round Magnet
1 x Cable
Note:
1. Connect the plug correctly according to the wiring diagram.
2. The Hall switch is an NPN normally open type, and the detection distance of the Hall switch needs to be within 10 mm. The Hall switch is installed with a diameter of 12 mm and a wire length of 1m or less.
3. Avoid strong electromagnetic interference, the measurement wire is best to use shielded wire or twisted pair wire.
4. The counter and the clear input switch or circuit should be as close as possible to the terminals of the counter to make the line as short as possible.
5. Avoid the same tube or stranded wiring with strong electric wires or power wires to avoid unnecessary interference. If necessary, please use shielded wires, and the shielding layer is connected to the counting terminal +.
6. It is not recommended to use mechanical switches or micro switches, because their life is relatively short, it is easy to miscount after a long time; if using mechanical switches or micro switches, please try to use better quality , so as not to m
7.Please note that the new type and old type of this product will be sent randomly, and make sure you will not mind before ordering.
Item Type: Tachometer
Operating Voltage: DC 8-24V, 40mA
Display: 0.56inch green LED, 4 digit reading
Measuring Range: 10-9999rpm
Measuring Accuracy: ±0.1%, reading±1digit
Display Refresh Rate: >3 times/sec
Overrange Display: Display 1 or -1 in the first digit position, none in the last three digit positions
Hall Proximity Switch Type: NPN NO
Tachometer Size: 79x26x43mm / 3.11x1.02x1.69in
Package List:
1 x LED Tachometer
1 x Hall Proximity Switch
1 x Round Magnet
1 x Cable
Note:
1. Connect the plug correctly according to the wiring diagram.
2. The Hall switch is an NPN normally open type, and the detection distance of the Hall switch needs to be within 10 mm. The Hall switch is installed with a diameter of 12 mm and a wire length of 1m or less.
3. Avoid strong electromagnetic interference, the measurement wire is best to use shielded wire or twisted pair wire.
4. The counter and the clear input switch or circuit should be as close as possible to the terminals of the counter to make the line as short as possible.
5. Avoid the same tube or stranded wiring with strong electric wires or power wires to avoid unnecessary interference. If necessary, please use shielded wires, and the shielding layer is connected to the counting terminal +.
6. It is not recommended to use mechanical switches or micro switches, because their life is relatively short, it is easy to miscount after a long time; if using mechanical switches or micro switches, please try to use better quality , so as not to m
7.Please note that the new type and old type of this product will be sent randomly, and make sure you will not mind before ordering.
| Brand Name | Marhynchus |
|---|---|
| Part Number | Marhynchusigp1smnfw7 |
