Max 300A 12 Volt 4-Terminal Continuous Duty Solenoid Relay Nickel-Plating | Fits for Golf Carts Winch Marine RV Heavy Duty Machine, SPST 12VDC 12V Solenoid Relay | OE# 70-111224, 3635820, 1114208
$15.77
- OEM number: 70-111224 | 3635820 | 1114208 | 1114218 | 1114223 | 1114534 | 1114547 |
- Compatible with DELCO 1114208, 1114218 | JOHNSON ELECTRIC 5117340 | MOTORCRAFT SWX88 | PRESTOLITE 15-88, SWX-88, 15-132, SAS4202, 15-108 | YALE 502265300 |
- Voltage: 12VDC | Resistance: 14Ω | Inrush current: 300A | Continuous Working Current recommend: 150A |
- Body Shell Plating: Nickel-Plating | Mounting Bracket: Flat, Open Slots | Mounting holes: 5/16 x 19/32, 2-13/64 on centers |
- Contact Form: SPNO (Single Pole Normally Open) | Contact Termination: 5/16”-24 UNF Thread | Coil Termination: #10-32 UNF Thread |
- WARNING: This is a Normally Open solenoid, Max 10 min continuous duty @ 150Amp, NEED BREAK otherwise it will be overheated.
- Warranty: For any reason, if you are not satisfied with your purchase, contact us directly. We offer 1-year warranty, 100% satisfaction guarantee.
This product is fulfilled by seller
the starter solenoid relay is a critical component in a vehicle's starting system, responsible for engaging the starter motor by allowing high-current flow from the battery. It plays a crucial role in the vehicle's ignition process and ensures smooth and reliable engine starting. If you experience starting problems with your vehicle, the starter solenoid relay is one of the components that should be checked for potential issues.
| Brand Name | LLNSEAUTO |
|---|---|
| Part Number | S041-1114208N-12V |
| Is the item dishwasher safe? | No |
