J-Tech Digital Premium Quality 1080P HDMI to HDMI + Audio (SPDIF + RCA Stereo) Audio Extractor Converter (JTDAT5CH)
- Extracts digital audio from an HDMI input and converts it to either a 2-channel analog stereo output or a 5.1-channel audio output. ARC functionality is not supported. For the ARC-compatible version, refer to ASIN: B00YHS5E6Q.
- Supports the highest video resolution to 1080p. Supports 225MHz/2.25Gbps per channel bandwidth.
- Supports 12bit per channel (36bit all channel) deep color. Supports HDCP, Video EDID Pass Through; Plug & Play.
- Audio EDID Settings: 2CH for L/R or SPDIF stereo output; 5.1CH for SPDIF Output, Supports uncompressed audio such as LPCM. Supports compressed audio such as DTS Digital, Dolby Digital.
- Provides the Best Flexibility through Three NEW Audio EDID Settings: Pass, 2CH and 5.1CH, Support 3D video (To get 3D, all units connected to the splitter outputs must support 3D). This item supports Apple TV and various Blu-ray player and satellite receivers.
To improve our customers experience, we posted the following three methods if you experience no sound from output.
1. The EDID-Option Switch: Switch the EDID-Option buttom in the front, change it between 2CH, 5CH or pass.
2. Turn Off Dolby Digital Plus: TOSLINK (SPDIF) does not support Dolby Digital Plus, you need to turn off Dolby Digital Plus function, then the sound can go through the extractor.
a: Amazon Fire TV or Amazon Fire TV Stick
Settings - Display Sound - Audio - Dolby Digital Output - Dolby Digital Plus off
b: Apple TV
Settings Audio Video - Dolby Digital - on
c: Chromecast
Chromecast plays the contents from your video source, please make sure to turn off the Dolby Digital Plus on the video source through the play devices.
3. Do Not use HDMI to DVI or HDMI to VGA cable, will result in no audio come out. Instead, please use HDMI to HDMI cable.
| Brand Name | J-Tech Digital |
|---|---|
| Part Number | JTDAT5CH |
