Alinan 3pcs TEC1-12712 Semiconductor Refrigeration Tablets TEC1-12712 12V 12A Heatsink Thermoelectric Cooler Cooling Peltier Plate Module 40x40MM
$16.99
- 【Chip Model】: TEC1-12712
- 【Dimensions】: 40x40x3.3mm component logarithm 127
- 【Wire Size】: wire length 300±5mm RV standard wire single head 5mm
- 【Maximum Temperature Difference】: Tmax (Qc = 0) 68 °C or more
- 【Working Current】: Imax=12A (when 15Vmax voltage is started)
This product is fulfilled by seller
Feature:
Model: TEC1-12712
Dimensions: 40x40x3.3mm
Wire Size: wire length 300±5mm RV standard wire single head 5mm
Maximum Temperature Difference: Tmax (Qc = 0) 68 °C or more.
Working Current: Imax=12A (when 15Vmax voltage is started)
Rated Voltage: DC12V (Vmax: 15.5V)
Cooling Power: Qcmax 107W
Assembly Pressure: 85N/cm2
Working Environment: Temperature range -55 °C ~ 83 °C (excessive ambient temperature will directly affect cooling efficiency)
Storage Conditions: -40~60°C
Model: TEC1-12712
Dimensions: 40x40x3.3mm
Wire Size: wire length 300±5mm RV standard wire single head 5mm
Maximum Temperature Difference: Tmax (Qc = 0) 68 °C or more.
Working Current: Imax=12A (when 15Vmax voltage is started)
Rated Voltage: DC12V (Vmax: 15.5V)
Cooling Power: Qcmax 107W
Assembly Pressure: 85N/cm2
Working Environment: Temperature range -55 °C ~ 83 °C (excessive ambient temperature will directly affect cooling efficiency)
Storage Conditions: -40~60°C
| Brand Name | Alinan |
|---|---|
| Part Number | Alinan |
| Item Height Unit | Inches |
| Item Height base to top | 0.130000 |
| Item Length Unit | Inches |
| Item Length Longer Edge | 1.570000 |
| Item Width Unit | Inches |
| Item Width Shorter Edge | 1.570000 |
