PF10000431614
In stock
ARTILAURA 240-33 ohm Fuel Sending Unit 6" (150mm) Stainless Steel Water Fuel Gas Tank Level Sender for Boat Marine AUTO Car Truck Vehicle
$33.99
- [Material]: Fuel sending unit is made with heavy duty stainless steel. This water level sensor is reed switch, durability and reliability, steady output signal. No adjustment needed for tank.
- [Wide Application]: The fuel level sender is suitable for Boat, Auto,Trucks, Buses and Marine field. Fuel tank sending unit it for Fuel Level Gauge,Water Level Gauge and any kinds of liquids without impurities.
- [American Standard Output]: Length range of fuel sender to choose: 5 inch-18 inch. The Fule/Water Level Sensor with American standard output 240-33 ohms (240 ohms at empty, 33 ohms at full). The fuel sending unit comes with 1 x Sensor, 1 x Gasket, 5 x Screws and 1 x instructions.
- [Easy to Install]: SAE 5 hole mounting pattern, easy to install and hookup.The well-written and illustrated instructions are straight forward that will easy to follow.
- [Attention]: 1 inch(25mm) clearance must be maintained between the tank bottom and the float retaining collar in addition to adjacent side or baffle of tank.
This product is fulfilled by seller
Specifications:
- Protection ank: IP67
- Resolution range: 21 mm
- Assembly: SAE standard 5 holes
- Rated current for alarm switch: 500mA
- Output signal: 240~33 ohm (Standard American)
- Operating temperatures: - 40 to 85 Celsius
- Fit for Fuel Level Gauge and Water Level Gauge
- Mounting: 5 pieces of M5 screws and 2 mm thick gasket
- Protection ank: IP67
- Resolution range: 21 mm
- Assembly: SAE standard 5 holes
- Rated current for alarm switch: 500mA
- Output signal: 240~33 ohm (Standard American)
- Operating temperatures: - 40 to 85 Celsius
- Fit for Fuel Level Gauge and Water Level Gauge
- Mounting: 5 pieces of M5 screws and 2 mm thick gasket
| Brand Name | ARTILAURA |
|---|---|
| Part Number | AR-A5-150-240 |
