AGULIUM 20T Hydraulic Ram Jack + cp-180 Hand Pump with Pressure Gauge, 2 Inch Stroke Low Profile Hydraulic Cylinder Jack Porta Power Kit, Portable Small Hydraulic Jack 20Ton

Details

Clear Gauge: It makes it easier for you to observe changes in pressure and make timely adjustments.

Application

It can be used for the installation and maintenance of large and medium-sized mechanical equipment in construction sites, petroleum, electric power, metallurgy, ships, bridges, steel, and other industries. It can be used with punching machines, cutting machines, bending machines, cable cutter hydraulic pliers, and other machines.

Specification

• Cylinder Model: RSC-2050
• Hand Pump Model: CP-180
• Color: Green
• Shape: Cylinder
• Material: Steel
• Process: Plastic Spraying
• Interface Size: 3/8''
• Maximum Output Pressure:700/10000KG/CM2
• Output Pressure: High Pressure 60KG/CM2
• Length of Oil Pipe: 1m/3.28ft
• Total Tonnage: 20T/44092lbs
• Stroke: 50mm/2in
• Travel: 50min
• Collapsed Height: 105mm/4.13in
• Extended Height: 155mm/6.1in
• Cylinder Jack Size(D*H): 9*10.6cm/3.54*4.17inch
• Hand Pump Size: 34*10*14cm/13.39*3.94*5.51inch
• Package Size: 37.5*22.5*16.5cm/14.76*8.86*6.5inch
• Gross Weight: 7kg/15.43lbs
• Net Weight: 6kg/13.23lbs

Package Included

• 1* Hydraulic Cylinder Jack
• 1* Hand Pump

Notes

• 1.Please use the product on a flat surface, not on soft or rough ground, and do not apply unilateral force to the spindle.
• 2.If there is a slight oil leak at the interface, you can wrap it with a raw material belt (not included).
• 3.There is hydraulic oil in the hydraulic pump. After a long time of use, you need to refuel yourself, it is recommended to use No.15 hydraulic oil (not included).
• 4.Before use, the interface between the jack and the pump should be installed firmly, otherwise it will leak oil. A slight oil leak at the interface is normal.
• 5.The first time you use it, you need to press the hydraulic pump a few more times to remove the air inside the jack.
