Srliya DC12V/24V LED Light Human Body Induction Kit Smart Stair Step Light Sensor Controller

Item Type: LED Light Induction Kit
Product Model: LTK01
Input Voltage: DC12V/DC24V
Output Voltage: DC12V/DC24V
Output Power: Single Step ?15W, Total Power: ?400W
Ports: 32
Induction Head: 2 (AB)
Class: IP20
Signal Mode: Human Body Induction
Control Method: Induction Control
Control Range: Approx. 30 meter / 98.4ft
Interface Type: For DuPont Interface
Applicable Scene: Home, hotel, bar
Insert the LED strips into the controller ports of the corresponding stair steps in sequence.
For Example:
The lamps on the first step are directly inserted into the interface 1 corresponding to the controller; the lamps on the second step are directly inserted into the interface 2 corresponding to the controller; the lamps on the third step are directly inserted into the interface 3 corresponding to the controller; and so on
This controller has 32 ports. According to the actual situation, you can insert the required light strips in order and do not need to pay attention to the redundant ports. You can also add light strips later.
Lamp Controller Interface: For DuPont interface, left +, right ?
LED Stair Light Sensor Controller Operating Instruction:
Number of Stair Steps Settings:
Press and hold the Settings 2 button for 2s, the red light flashes, and then press the Settings 1 button to select the number of stairs to set. After selecting, release the hand for 5s and the red light will turn off, and the setting is complete.
Lighting Speed Setting:
Press and hold the Setting 1 button for 2s, the red light flashes, and then press the Setting 1 button to set the speed 1?5, 1 is the slowest, 5 is the fastest; The light goes out and the setting is complete.
Brightness Settings:
When the LED Light is on, press the Setting 2 button to enter the 5 level brightness selection lighting delay setting:
Press and hold Setting 1 button for 3s, enter the delay settings 1?5
