Beduan 4 mm OD Pneumatic Air Line Tubing Nylon Air Hose for Fluid Transfer or Air Brake System 32.8ft (Black)
- 【Model】PA Nylon Tube, Standard SAEJ844 Tubing
- 【Size】4mm OD（5/32''). 2.5mm ID. Wall Thickness : 0.75mm.
- 【Working Pressure】2.5Mpa/362psi. Burst pressure: 6.3Mpa/913psi
- 【Working Temperature】-40℉-248℉ / -40℃--120℃
- 【Feature】Abrasion resistant, heat resistant and chemical resistant
Material:PA( Polyamide)
Length: 10Meter/ 32.8ft
Working pressure: 2.5Mpa/362psi
Burst pressure: 6.3Mpa/913psi
Use medium: Air, water, lubrication
Operating temperature: -40℉-248℉ / -40℃--120℃
Characteristics of PA Nylon Tube
Nylon tube has good physical and chemical properties: wear resistance, can be used in the condition of sand, iron filings;Smooth surface, reduce resistance, can prevent rust and deposition;Soft, easy to bend, easy to install and Simple processing.
Abrasion resistant, heat resistant and chemical resistant, Simple installation, permeability; can be used as an insulator;It has a long service life.
Therefore, it is widely used in automobile, electrical equipment, mechanical parts, traffic equipment, textile, paper making machinery, etc
This is a metric tube,if you want choose Inch size,please search ASIN:B07Q2VJR6D
| Brand Name | beduan |
|---|---|
| Part Number | 1kl-03200-GZN |
| Maximum Pressure | 913.000000 |
| Inside Diameter Unit | Millimeters |
| Inside Diameter Decimal Value | 2.500000 |
| Outside Diameter Unit | Millimeters |
| Outside Diameter Decimal Value | 4.000000 |
| Item Length Unit | Inches |
| Item Length Longer Edge | 393.600000 |
| Item Width Unit | Inches |
| Item Width Shorter Edge | 0.150000 |
| Item Length Unit | Inches |
| Item Length End to End | 393.600000 |
