uxcell Pneumatic Tubing, 10mm(0.4") OD x 8mm(0.31") ID x 2m(6.56ft) Air Brake Tube Nylon Air Line Water Hose Translucent
$18.84
- Features: Nylon tube has acid and alkali resistance, corrosion resistance, high-temperature resistance, high-pressure resistance, wear resistance, aging resistance and other properties
- Advantages: The nylon tube has smooth inner and outer surfaces, flexible and elastic, is resistant to bending, small bending radius. The working temperature is -40°C~120°C, and the working pressure is 2.6Mpa. Bright color, long-term work does not fade.
- Size: Pneumatic Hose Tube Measures 0.31-inches inside diameter by 0.4-inches outside diameter by 6.56-feet total length. thin tube wall providing higher flow rates and working pressure
- Tips: If you want to use the nylon tube for a long time, it is recommended to work under the rated working pressure and temperature.
- Application: Widely used to transport compressed air, water, fuel oil, liquid, etc., assemble various pneumatic tools, pneumatic automation machinery, air compressors and various connected pneumatic components, used in industry and pneumatic supporting in various fields pipeline.
This product is fulfilled by seller
Specifications:
Material: Nylon PA6
Color: Translucent
Length: 2M(6.56ft)
Size: 8mm x 10mm(IDxOD)
Elongation: >30%
Density: 1.14-1.15g/cm3
Tensile strength: >60.0Mpa
Bending strength: 90.0 MPa
Notched impact strength: (KJ/m2) > 5
Melting point: 215-225 Celsius Degree
Operating temperature: -40 to 105 Celsius Degree
Package Content:
1 X Nylon Tubing
Features:
1.Nylon PA6 is strong, lightweight and has a very low moisture absorption rate compared to other nylons.
2.By not absorbing moisture, nylon PA6 will remain more flexible, which in turn extends it's service life.
3.Nylon tubing can be used with standard push-to-connect fittings and compression fittings for simple installation.
4.Because of it's semi-rigid properties, nylon tubing offers a thinner tube wall providing higher flow rates and working pressure.
5.can be use in the -40 ℃ ~ +60 ℃ temperature environment, so nylon tube can be used to transport compressed air,water, fuel oil, chemical solvents, liquid food.
6. safe and reliable application in: air, water, lubricants, instrument lines, irrigation control systems,textile mills, fuel delivery pipe, vacuum systems, air conditioning systems, And hydraulic brake system, oscillation insulator and other industries.
Tips:
It must be under the rated working pressure and temperature, if you want to keep this Nylon Tube in a long term service life.
As temperature rise, working pressure shall be reduced correspondingly, if go beyond the limiting, the tube can rupture.
Material: Nylon PA6
Color: Translucent
Length: 2M(6.56ft)
Size: 8mm x 10mm(IDxOD)
Elongation: >30%
Density: 1.14-1.15g/cm3
Tensile strength: >60.0Mpa
Bending strength: 90.0 MPa
Notched impact strength: (KJ/m2) > 5
Melting point: 215-225 Celsius Degree
Operating temperature: -40 to 105 Celsius Degree
Package Content:
1 X Nylon Tubing
Features:
1.Nylon PA6 is strong, lightweight and has a very low moisture absorption rate compared to other nylons.
2.By not absorbing moisture, nylon PA6 will remain more flexible, which in turn extends it's service life.
3.Nylon tubing can be used with standard push-to-connect fittings and compression fittings for simple installation.
4.Because of it's semi-rigid properties, nylon tubing offers a thinner tube wall providing higher flow rates and working pressure.
5.can be use in the -40 ℃ ~ +60 ℃ temperature environment, so nylon tube can be used to transport compressed air,water, fuel oil, chemical solvents, liquid food.
6. safe and reliable application in: air, water, lubricants, instrument lines, irrigation control systems,textile mills, fuel delivery pipe, vacuum systems, air conditioning systems, And hydraulic brake system, oscillation insulator and other industries.
Tips:
It must be under the rated working pressure and temperature, if you want to keep this Nylon Tube in a long term service life.
As temperature rise, working pressure shall be reduced correspondingly, if go beyond the limiting, the tube can rupture.
| Brand Name | uxcell |
|---|---|
| Part Number | a19051400ux0524 |
| Maximum Pressure Unit | Kilopascal |
| Maximum Pressure | 2.600000 |
| Inside Diameter Unit | Millimeters |
| Inside Diameter Decimal Value | 8.000000 |
| Inside Diameter String Value | 8 |
| Nominal Wall Thickness | 1.3 mm |
| Outside Diameter Unit | Inches |
| Outside Diameter Decimal Value | 0.400000 |
| Outside Diameter String Value | 0.4 |
| Item Length Unit | Inches |
| Item Length Longer Edge | 78.720000 |
| Item Width Unit | Inches |
| Item Width Shorter Edge | 0.400000 |
| Item Length End to End | 6.560000 |
| California Proposition 65 Warning Type | Chemical |
