TBS 5530 DVB-S2X DVB-S2 DVB-T2 DVB-C2 ISDB-T ATSC1.0 Digital TV Tuner USB Box for Live TV/ Window/ Linux/ IPTV Server

DVB-S/S2
QPSK:1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10
8PSK:3/5, 2/3, 3/4, 5/6, 8/9, 9/10
16APSK:2/3, 3/4, 4/5, 5/6, 8/9, 9/10
32APSK:3/4, 4/5, 5/6, 8/9, 9/10
DVB-S2X
QPSK: 1/4,1/3, 2/5 (S2-MODCODs)
1/2, 3/5, 2/3, 3/4, 4/5, 5/6
8/9, 9/10 (S2-MODCODs)
11/45, 4/15, 14/45, 7/15 8/15, 32/45
8PSK (8APSK-L): 3/5, 2/3, 3/4, 5/6, 8/9 (S2-MODCODs)
7/15, 8/15, 26/45, 32/45
16APSK: 2/3, 3/4, 4/5, 5/6, 8/9 (S2-MODCODs)
7/15, 8/15, 26/45, 3/5, 32/45
32APSK(32APSK-L): 3/4 ,4/5,5/6, 8/9, 9/10 (S2-MODCODs)
32/45 ,11/15,7/9 ,(2/3)
VCM: Yes
Symbol rate: 1 ~ 45Msymb/s
DVB-T2 and T2-Lite
Receiving channel: VHF band, UHF band
Bandwidth: 1.7, 5, 6, 7, 8MHz
FFT mode: 1K, 2K, 4K, 8K, 16K, 32K
1/32, 1/16, 1/8, 1/4, 1/128, 19/128 and 19/256 guard intervals
16, 32, 64, 128 and 256QAM modulations
Code rate: 1/2, 3/5, 2/3, 3/4, 4/5 and 5/6
DVB-T:
6, 7 and 8MHz channel bandwidths
2 and 8K FFT
QPSK, 16 and 64QAM
1/2, 2/3, 3/4, 5/6 and 7/8 code rates
DVB-C2:
6 and 8MHz channel bandwidths
1/64 and 1/128 guard intervals
16, 64, 256, 1024, 4096 QAM
2/3, 3/4, 4/5, 5/6, 8/9 and 9/10 code rates
DVB-C
1.7 to 7.2 Msym/s
16, 32, 64, 128 and 256QAM
0.15 roll-off factor
ISDB-T
6, 7 and 8MHz bandwidth
2, 4 and 8K FFT
1/32, 1/16, 1/8 and 1/4 guard intervals
QPSK, 16QAM and 64QAM
ISDB-C
5.274 Msym/s
0.13 roll-off factor
64 and 256QAM
TSMF (Transport Streams Multiplexing Frame)
J.83B (ITU-T J.83 v3.0 Annex B)
5.056941, 5.360537, 5.6 Msym/s
0.18 and 0.12 roll-off factor
64 and 256QAM
ATSC1.0
6MHz channel bandwidths
8VSB modulation
2/3 code rate

Power consumption
Input/ Power: 5V/5W
temperature: 0 ~ 60℃
System Requirements: Windows XP / Vista/ 7/8/10, Linux

Package Contents
1 x TBS5530
1 x USB cable
1 x F-IEC
