Heavy Duty Air Pressure Switch Sunny H1, 1 port, 140-175 PSI, 25 Amp, Auto/Off Cut-Out Lever
$0.00
- Heavy Duty SUNNY 140-175 PSI air compressor pressure switch, Single Port.
- MAX PRESSURE: 200 PSI MIN CLOSE: 60 PSI, 25AMP
- DIFFERENTIAL: 28-40 PSI
- 1/4" COMPRESSION UNLOADER VALVE CONNECTION, 1/4" FEMALE NPT TANK CONNECTION.
- 1PH: 115v,230v; 3PH: 230V,575V; DC: 32V,115V,230V
This product is fulfilled by seller
This Sunny SU-H1 air-compressor pressure switch controls an electrically driven air compressor in a power circuit when the adjustable threshold upon falling is reached and is set to turn off at 175 psi. The switch has a 1/4" NPSF internal fluid connection. The adjustable cut-out range is 60-200 psi. The switch is diaphragm actuated and has a fixed differential. The threshold, or setting point, upon rising adjusts with a screw nut. The switch has screw terminal electrical connections. The maintained manual cut-out lever has auto and off positions.
| Brand Name | ALL Tool Depot |
|---|---|
| Part Number | SU-H1_a |
| Wattage | 2875.000000 |
| Wattage Unit | Watts |
| Current Rating Unit | Amps |
| Current Rating | 25.000000 |
| Operating Voltage Unit | Volts |
| Operating Voltage | 230.000000 |
| Control Method | Touch |
