XANHAM DB25 25 Pin 16 Feet(5 Meter) Two Row Straight Through Serial Cable, Double Shielded(Metal Braiding&AL-foil), Female to Male, Black, SC920S10FM
$22.99
- DB25 TWO ROW(NOT VGA Three Row) Female to Male: With DB25 two row female connector in the one end and male connector in the other, XANHAM DB25 cable connects your devices easier.
- Straight Through Connection: All 25 Pins are wired straight through order by 1-1, 2-2, 3-3, ...... 24-24, 25-25, G-G.
- Stable Connection: 28AWG tinned copper conductors and gold-plated pin provide smooth connection basic, while metal braiding and AL-foil shielding structure can prevent external interference for safe and stable connection.
- Durabe Desigh: XANHAM DB25 cable are all produce through two times injection molding(internal molding and outer molding) which can maintain a more stable structure with cable and connectors. Cable are UL Listed with VW-1 fire resisitance for using safety both in-wall and out-wall.
- Compatibility: It is widly use for computer or server connecting to the equipments with DB25 connector like scanner, printer, plotter, switches, camera, test equipment, etc.
This product is fulfilled by seller
Item specification Connector: DB25 female to male Conductor Gauge: 28 AWG Conductor Material: tinned copper Shielded Type: Metal braiding + AL-foil Connection Type: Straighe through(1-1, 2-2, 3-3, 4-4, 5-5, 6-6, 7-7, 8-8, 9-9, 10-10, 11-11, 12-12, 13-13, 14-14, 15-15, 16-16, 17-17, 18-18, 19-19, 20-20, 21-21, 22-22, 23-23, 24-24, 25-25, G-G.) Cable OD(Overall Diameter): 7.5mm Color: Black
| Brand Name | XANHAM |
|---|---|
| Part Number | SC920S |
| Data Transfer Rate | 0.480000 |
| Gauge Decimal Value | 28.000000 |
| Cable Length Decimal Value | 1.000000 |
| Cable Length String Value | None |
| Cable Length Unit | Meters |
| Indoor Outdoor Usage | Indoor |
