4Pcs LCD1602 1602 LCD Module Blue Screen 16x2 Character LCD Display with IIC I2C Serial Interface Adapter Module

Be the first to review this product

$0.00

1602 lcd screen can display 2-lines x 16-characters with built-in industry standard HD44780 equivalent LCD controller
LCD1602 1602 LCD module working voltage: 5V; To come with a potentiometer, which is applied to adjust backlight and contrast; How to wire: GND—GND; VCC—VCC; SDA—A4; SCL—A5
It only takes two I/O port thus saving more for other usages. You can adjust the contrast by the potentiometer at its back. If you don’t want the back light, you can also unplug the jumper cap at the LCD back.
LCD1602 1602 LCD module compatible with copiers, fax machines, laser printers, industrial test equipment, networking equipment such as routers and storage devices.
1602 display function: LCD display with I2C serial interface can be applied to display real time clock, temperature, humidity and so on.

This product is fulfilled by seller

Skip to the beginning of the images gallery

Details

More Information

Reviews

Questions

1602 16X2 character LCD display module blue backlight
Backlight: Blue with black on yellow
Fully assembled and tested serial LCD 16x2 module
Display Format: 2-lines X 16-characters
Working Voltage: 5V
The module can be easily interfaced with a MCU
Pin Definition: VCC, GND,SDL and SCA
Contrast Adjust: Potentiometer
Backlight Adjust: Jumper
Wiring: GND: negative system power supply VCC: system power supply positive SDA: IIC data cable SCL: IIC clock line Package include:
4 x LCD 1602 module with I2C interface adapter

More Information
Brand Name	Shutao
Part Number	13447-1
