MINISFORUM BD790I X3D Mini ITX Motherboard, Integrated AMD Ryzen 9 7945HX3D, up to 5.4 GHz, 16C/32T, 144MB Cache,PCIe 5.0 x16 Slot,2 x PCIe 5.0 M.2 Slots, DDR5, HDMI/DP/USB-C, WiFi 6E/BT 5.3

Be the first to review this product

$749.99

Powerful Flagship Processor: The BD790I X3D is powered by the AMD Ryzen 9 7945HX3D processor, based on the Zen 4 architecture,16 cores/ 32 threads, designed to meet the highest performance standards. With a 30% performance increase over the previous generation, this processor is built for seamless multitasking, extreme gaming, and content creation. Whether running intensive applications or playing resource-intensive games, this CPU can handle all tasks with ease.
Super Game Stability & Lightning-Fast Response: The system is equipped with 144MB ultra-large capacity cache (L2+L3) and 5.4GHz acceleration frequency, combined with AMD's 3D V-Cache technology, which improves performance by optimizing cache, providing ultra-low latency, extremely fast response, and even in the most demanding game scenes, the average FPS and 1% low frame rate performance will be improved. Whether it is FPS or complex strategy games, it gives you an advantage over the competition.
Efficient Cooling System: Even under the heaviest gaming loads, this system stays cool and quiet thanks to a carefully designed cooling solution. A pre-installed fanless heatsink (supports 12cm fan) with 80% motherboard heatsink coverage ensures efficient heat management. An active SSD cooler ensures PCIe 5.0 runs at full speed, delivering consistent performance during long gaming or creative sessions.
Unmatched Storage and Memory: Unlock lightning-fast storage with dual PCIe 5.0 SSDs and DDR5 memory, delivering up to 10GB/s read speeds. With memory expandable up to 96GB, your system will be future-proof and ready for heavy gaming, content creation, and multitasking. Thanks to the BD790I X3D motherboard's low power consumption, this high-speed configuration is optimized for performance and energy efficiency.
Low Power but Powerful: The BD790I X3D motherboard delivers 90% of Ryzen 9 7950X3D's power while consuming less energy and producing minimal noise. Ideal for compact ITX builds or high-load operations, it ensures no performance compromise for energy savings. Supports triple-display via HDMI 2.1/DP 1.4/USB-C and features WIFI 6E & Bluetooth 5.3 for fast wireless connections.

This product is fulfilled by seller

Skip to the beginning of the images gallery

Details

More Information

Reviews

Questions

CPU：AMD Ryzen 9 7945HX3D, 16 Cores/32 Threads
(128M Cache, up to 5.4 GHz)
GPU：AMD Radeon 610M
Memory Types：DDR5 SODIMM
Max Memory Size：96GB
Max # of DIMMs：2
Max # of Memory Channels：2
ECC Memory Supported：NO
Storage：2×M.2 2280 PCIe5.0 SSD Slots
Wireless：M.2 2230 Key-E (WiFi6e, BT5.3)
Video Output：HDMI2.1 ×1
DisplayPort1.4 ×1
USB-C ×1
Audio Output：HDMI2.1 ×1
DisplayPort1.4 ×1
USB-C ×1
Line Out ×1
Ports & Buttons：RJ45 2.5G Ethernet Port×1
USB3.2 Gen2 Type-C Port(Alt DP) ×1
USB3.2 Gen1 Type-A Port ×2
USB2.0 Type-A Port ×2
4-pin CPU Fan header ×1
4-pin System Fan header ×2
4-pin SSD Fan header ×1
USB 3.2 Gen 1 header ×1
Front Panel Audio header ×1
System Panel header ×1
Form Factor：Mini-ITX Form Factor(170x170x1.6mm)
Expansion Slot：PCIe 5.0 X16 connector ×1
CPU Cooler height：37mm(No fan installed)

More Information
Brand Name	MINISFORUM
Part Number	00001
Compatible Processors	Ryzen 9
Memory Clock Speed	5.400000
Memory Clock Speed Unit	GHz
FCC ID	2A49R-MINIPC
