HUIZHUGS Optical Fiber Cable 3M/10M Fiber Optic Internet Cable LC/UPC-LC/UPC OM3 LSZH FTTH Multi-Mode Single Core Fiber Optic Patch Cord Cable 2.0mm Optical Fiber Extension Cable(10M LCupc)

Key Features:
Connector Type:LC/UPC to LC/UPC
Length Options:3 Meters (9.8ft) or 10 Meters (32.8ft)
Fiber Type:OM3 50/125 Multi-Mode
Core:Single Core
Cable Diameter:2.0mm
Jacket Material:LSZH (Low Smoke Zero Halogen) for safety and durability
Insertion Loss:0.3dB
Return Loss:50dB
Operating Temperature:-20°C to +75°C
Why Choose Our Fiber Optic Patch Cords?
High Performance:Ensures low insertion loss and high return loss for seamless data transmission.
Durable Design:LSZH jacket provides excellent protection against environmental factors and ensures safety in case of fire.
Wide Compatibility:Compatible with OM3 multi-mode fiber optic systems, ideal for high-speed networks.
Easy to Install:Plug-and-play design for quick and hassle-free installation.
Trusted Quality:Manufactured to meet international standards for reliability and performance.
Applications:
Data Centers
Telecommunications
FTTH (Fiber to the Home)
LAN/WAN Networks
CCTV & Security Systems
Server Rooms
Package Includes
1 x LC/UPC-LC/UPC Fiber Optic Patch Cord (3M or 10M)
Technical Specifications:
Connector Type: LC/UPC to LC/UPC
Fiber Type: OM3 50/125 Multi-Mode
Insertion Loss: 0.3dB
Return Loss: 50dB
Operating Temperature: -20°C to +75°C
Cable Diameter: 2.0mm
Jacket Material: LSZH
Differences between APC and UPC
The main difference between APC and UPC connectors is the fiber endface. APC connectors feature a fiber endface that is polished at an eight-degree angle; UPC connectors are polished with no angle. UPC connectors are not exactly flat, however; they have a slight curvature for better core alignment. Another more obvious difference is color. UPC connectors are blue while APC connectors are green.
==========
Hign-concerned Chemical : None
Fiber Type : Multimode
Connector Type : LC/UPC
Item Length : 10m
Model Number : LC/UPC-LC/UPC
Fiber
