TAILONZ PNEUMATIC 3 Way 2 Postion Air Hand Lever Operated Valve 1/4"NPT Pneumatic Solenoid Valve Manual Control Push-Pull 3H210-08
$0.00
- 【Product Name】 3 Way 2 Position Hand Pull Valve
- 【Size】1/4"NPT 【Working Medium】Air
- 【Working Pressure Range】25Psi~116Psi
- 【Product Features】Controls Air Flow On or Off
- 【Fittings】We provide matching fittings,You can connect directly to your 1/4 "or 6mm tube
This product is fulfilled by seller
★Product Feature:
①Manual Operation, Smooth Operation, Accurate And Reliable Positioning.high Precision Stem Fit Degree Is High Good Air Tightness.
②The Inner Hole Is Processed By Special Process, With Small Friction Resistance And Long Service Life.
③Driven Automatically By Compressed Air. With Hand Lever, Can Be Controlled Manually To Deal With Some Special Situations.
④Widely Used To Control The Flow Of Various Types Of Fluids Such As Air, Water, Mud, Liquid Metals, Etc.
⑤The Three-port Two-position Manual Reset Type Manual Valve Adopts Spring Steel Ball Positioning, Which Is Responsive And Easy To Switch. Please Pay Attention To Excessive Force And Control Position Error Caused By Mistake.
★Product Specification:
Hand Pull Valve Model: 3H210-08;Type: Manual
Port Size: Air Inlet (P)=1/4 inch NPT,Air Outlet(A B)=1/4 inch NPT,Air Exhaust(R S)=1/8 inch NPT
Working Pressure Range: 0~0.8Mpa (0~116psi);
Working Temperature:0~60℃ (0~140℉)
Position and Port Number: 3 Port 2 Position.
★Package Included:
1 × 3H210-08（Hand Lever Operated Solenoid Valve）
1 × Teflon Tape
2 × PC6-02
1 × Pneumatic Muffler SL-01
①Manual Operation, Smooth Operation, Accurate And Reliable Positioning.high Precision Stem Fit Degree Is High Good Air Tightness.
②The Inner Hole Is Processed By Special Process, With Small Friction Resistance And Long Service Life.
③Driven Automatically By Compressed Air. With Hand Lever, Can Be Controlled Manually To Deal With Some Special Situations.
④Widely Used To Control The Flow Of Various Types Of Fluids Such As Air, Water, Mud, Liquid Metals, Etc.
⑤The Three-port Two-position Manual Reset Type Manual Valve Adopts Spring Steel Ball Positioning, Which Is Responsive And Easy To Switch. Please Pay Attention To Excessive Force And Control Position Error Caused By Mistake.
★Product Specification:
Hand Pull Valve Model: 3H210-08;Type: Manual
Port Size: Air Inlet (P)=1/4 inch NPT,Air Outlet(A B)=1/4 inch NPT,Air Exhaust(R S)=1/8 inch NPT
Working Pressure Range: 0~0.8Mpa (0~116psi);
Working Temperature:0~60℃ (0~140℉)
Position and Port Number: 3 Port 2 Position.
★Package Included:
1 × 3H210-08（Hand Lever Operated Solenoid Valve）
1 × Teflon Tape
2 × PC6-02
1 × Pneumatic Muffler SL-01
| Brand Name | TAILONZ PNEUMATIC |
|---|---|
| Part Number | 3H210-08 |
| Inlet Connection Size Unit | Inches |
| Inlet Connection Size | 0.25 |
| Maximum Operating Pressure | 116.000000 |
| Outlet Connection Size Unit | Inches |
| Outlet Connection Size | 0.25 |
