PF10000395747
In stock
ARTILAURA 240-33 ohm Fuel Sending Unit 5"(125mm) Stainless Steel Water Fuel Gas Tank Level Sender for Boat Marine AUTO Car Truck Vehicle
$28.99
- [Material]: Fuel sending unit is made with heavy duty stainless steel. This water tank level sensor is reed switch, durability and reliability, steady output signal. No adjustment needed for tank
- [Wide Application]: The fuel level sender is suitable for Boat, Auto,Trucks, Buses and Marine field. Fit for Fuel Level Gauge,Water Level Gauge and any kinds of liquids without impurities
- [Output]: Length range of fuel sensor unit to choose: 5 inch-18 inch. The Fule/Water Level Sensor with American standard output 240-33 ohms (240 ohms at empty, 33 ohms at full). The marine fuel sending unit comes with 1 x Sensor, 1 x Gasket, 5 x Screws and 1 x instructions
- [Easy to Install]: SAE 5 hole mounting pattern, easy to install and hookup.The well-written and illustrated instructions are straight forward that will easy to follow
- [Attention]: 1 inch(25mm) clearance must be maintained between the tank bottom and the float retaining collar in addition to adjacent side or baffle of tank
This product is fulfilled by seller
Specifications:
- Protection ank: IP67
- Resolution range: 21 mm
- Assembly: SAE standard 5 holes
- Rated current for alarm switch: 500mA
- Output signal: 240~33 ohm (Standard American)
- Operating temperatures: - 40 to 85 Celsius
- Fit for Fuel Level Gauge and Water Level Gauge
- Mounting: 5 pieces of M5 screws and 2 mm thick gasket
- Protection ank: IP67
- Resolution range: 21 mm
- Assembly: SAE standard 5 holes
- Rated current for alarm switch: 500mA
- Output signal: 240~33 ohm (Standard American)
- Operating temperatures: - 40 to 85 Celsius
- Fit for Fuel Level Gauge and Water Level Gauge
- Mounting: 5 pieces of M5 screws and 2 mm thick gasket
| Brand Name | ARTILAURA |
|---|---|
| Part Number | AR-A5-125-240 |
| Number of Positions | 1 |
| Current Rating Unit | Milliamps |
| Current Rating | 500.000000 |
