JUXINICE DB15 Extension Cable,D-SUB 15-Pin Female Adapter to Bare Wire, 15 Wires All Provided with Bare Wire End Cable-Black DB15 Female Connector-3FT
- DB15 Cable adopts Tinned copper core, anti-oxidation performance strong. Convenient terminal wire and Solder
- DB15 Solderless Breakout Connector adopts 26AWG double-layer shielded cable, which has stable signal transmission and good shielding effect
- 15 pin Cable line sequence color comparison table: 1-black, 2-brown, 3-red, 4-orange, 5-yellow, 6-green, 7-blue, 8-purple, 9-gray 10 white, 11 black and white, 12 brown white, 13 pink, 14 light green, 15 light blue
- D-SUB Cable Wrapped aluminum foil + high-density braided mesh forms a double-layer shield with strong anti-interference ability.
- DB15 Extension Cable Using PVC material for integrated injection molding DB15 adapter, sturdy and durable
DB15 serial connector adopts gold-plated connector, with fine solder joints, pluggable resistance and good contact to ensure high quality, durability and long service life. Effectively reduce the attenuation value, and the signal transmission is more efficient and stable
service life. Effectively reduce the attenuation value, and the signal transmission is more efficient and stable
Technical specifications:
Name: DB15 connector plug type: female
Connector material: punching pin gold-plated 3U male and female contact material: Copper
Shell material: environmental protection PP engineering material
Cable sheath: PVC
Shielding composition: wrapped aluminum foil + 96# metal woven mesh
Cable length: 1m / 3ft
Wire gauge: 26AWG
Package includes:
1×3FT DB15 female cable
| Brand Name | JUXINICE |
|---|---|
| Part Number | JUXIN |
| Gauge Decimal Value | 24.000000 |
| Cable Length Decimal Value | 3.000000 |
| Cable Length String Value | 3 |
| Cable Length Unit | Feet |
