PF10000391105
In stock
Connectors Pro 10P Male 10 Pack 1.27mm 0.05" Pitch Mini Dual Rows IDC FD Male Transition Connector Terminates to 0.635mm Flat Ribbon Cable (FD-10P-10PK)
$25.95
- Price is for 10-Pack 10p 1.27mm MALE / PLUG
- 2X5 10 Pins Double Row Male IDC connector (DIP Transition Connector) 0.05" x 0.05" (1.27mm x 1.27mm)
- Connector Orientation: Angled; NO STRAIN RELIEF
- Specifications: Mating Pin Size: 0.4mm square, Current Rating: 0.5A, Operating Temperature: -40°C to +105°C
- MATES WITH 1.27 mm (0.05") PITCH HEADERS; TERMINATES TO 0.635mm (0.025") pitch FLAT RIBBON CABLE
This product is fulfilled by seller
PRICE is for 10-PACK, Dual-Row 127mm Male IDC connector (DIP Transition Connector), 10 Position, IDC Flat Ribbon crimp Connectors These connectors mate with any 1.27mm spaced dual-row 10P plugs. The insulation displacement (IDC) contacts on these connectors allow them to be quickly and easily crimped onto flat ribbon cable. NUMBER OF PINS: 10P 2X5 Double Row Male IDC connector (DIP Transition Connector) 1.27mm x 1.27mm DUAL ROW IDC MALE CONNECTOR, NO STRAIN RELIEF MATES WITH 1.27 mm PITCH FC SOCKETS TERMINATES to 0.635mm (0.025") Pitch FLAT RIBBON CABLE
| Brand Name | Connectors Pro |
|---|---|
| Part Number | 127-FD10M-10PK |
