10x TIP120 NPN BJT ST Darlington Transistor TO-220 for Arduino with Free Diodes

TIP120 product info
Configuration: Single
Transistor Polarity: NPN
Collector- Emitter Voltage VCEO Max: 60 V
Emitter- Base Voltage VEBO: 5 V Collector- Base Voltage VCBO: 60 V
Maximum DC Collector Current: 5 A
Maximum Collector Cut-off Current: 200 uA
Mounting Style: Through Hole
Package / Case: TO-220-3 Maximum
Operating Temperature: + 150 C
Series: Darlingtons
Height: 9.15 mm Length: 10.4 mm Width: 4.6 mm
Brand: STMicroelectronics

1N4001 product info
Configuration:Single
Current, Forward, Continuous:1 A
Current, On-State, Non-Repetitive Peak:30 A
Current, Peak:10 μA
Current, Reverse:1 μA
Current, Surge:30 A
Diameter:2.7 mm
Dimensions:2.7 Dia. x 5.2 L mm
Diode Type:Standard Recovery Rectifier
Length:0.204" (5.2mm)
Mounting Type:Through Hole
Number of Pins:2
Package Type:DO-41
Primary Type:Rectifier
Rectifier Type:Switching
Speed, Switching:Standard
Temperature, Junction, Maximum:+175 °C
Temperature, Operating:-65 to +175 °C
Temperature, Operating, Maximum:+175 °C
Temperature, Operating, Minimum:-65 °C
Temperature, Operating, Range:-65 to +175 °C
