Zhpuostd Mini 4K HDMI Fiber Extender 4Kx2K 30Hz, HDMI 1.4a& HDCP1.2 Support,300m Transmission Distance with OM3 Multimode Fiber, 0~70°
- ???? ????????????:HDMI 1.4a, standard HDMI connector, real-time transmission of HDMI high-definition video signals.
- ?? ??????????:Support all modes 4k * 2 k@30hz resolution, video clear and stable, no compression transmission, no delay, no loss.
- ???? ??? ??? ????????????: HDMI high-definition images and data into 10G fiber signals, using OM3 multi-mode fiber, transmission distance of up to 300m.
- ??????? ??? ???????????:Length, width and height only 6.8cm*2.0cm*0.9cm, handy to carry, mini shape, easy to store.
- ?????? ?? ???:Plug and play, EMI/RFI resistant, no setup required.
Overview:
The Zhpuostd Mini 4K HDMI optical terminal supports 1.4A, adopts 850nm OM3 multi-mode fiber, transmission distance of 300 meters, no loss, supports resolution up to 4K*2K, and supports 3D. The 4k HDMI optical transmitter converts HDMI HD images and data into 10G optical fiber signals, the 4k HDMI optical receiver converts the received optical fiber signals into HDMI HD images and data, and also transmits the DHCP and EDID information obtained by HDMI back to the optical transceiver -T.Support HDCP,EDID transparent transmission. It not only breaks the limit of HDMI cable transmission length, but also is more convenient and flexible, and saves costs for customers. Mini 4K HDMI optical terminal meets European RoHS lead-free requirements.
Features:
Support DDC CEC HPD signal, HDMI 1.4a and HDCP1.2
Supports up to 300m transmission distance at 10.3 Gbps,using OM3 multimode fiber (850wavelength)
Supportall modes 4k*2k@30hz resolution,no compression transmission, no delay, no loss
Standard HDMI connector
Mini form factor, easy to use and install, plug and play, EMI/RFI resistant
If the HDMI source can provide sufficient HDMI 5V power supply, you can not use USB power supply.
Standard power consumption 1420 MW (transmitter end),1220MW (receiver end)
Operating temperature: 0 ~ 70°C
specification:
Video input/output interface: HDMI digital video/audio interface
Maximum transmission distance: 300m
Wavelength: multimode 850nm
Transmission rate: 10.3G
Pixel clock frequency: 340m
HDMI interface standard: HDMI1.4 backward compatible
Video resolution: 1080P@120hz, 3D
Maximum power consumption: 2.5w
Product net weight: 0.05kg*2, plus packaging: 0.35kg
Product shell (length * width * height) : 6.8cm*2.0cm*0.9cm
Working humidity: < 75%
| Brand Name | Zhpuostd |
|---|---|
| Part Number | 00001 |
