Bridgold 20pcs TIP125 PNP Darlington Bipolar Power Transistor -60v HFE:1000,3-Pin
$0.00
- High DC Current Gain - hFE = 2500 (typ) @ IC = 4.0 Adc
- Collector-Emitter Sustaining Voltage @ 100 mA VCEO(sus) = 60 Vdc (Min) TIP120, TIP125
- Low Collector-Emitter Saturation Voltage VCE(sat) = 2.0 Vdc (Max) @ IC= 3.0 Adc = 4.0 Vdc (Max) @ IC= 5.0 Adc
- Monolithic Construction with Built-In Base-Emitter Shunt Resistors
- Compact TO-220 Package
This product is fulfilled by seller
The Darlington Bipolar Power Transistor is designed for general-purpose amplifier and low-speed switching applications. TIP120, (NPN); TIP125 (PNP) are complementary devices.
Transistor Polarity:PNP
Power Dissipation Pd:65w
DC Collector Current:-5A
Collector Emitter Voltage V(br)ceo:-60V
DC Current Gain hFE:1000hFE
Transistor Case Style:TO-220
Minimum Operating Temperature:-65 °C
Operating Temperature Max:150°C
Dimensions:10.4 x 4.6 x 9.15mm
Package include:
20pcs*TIP125
Transistor Polarity:PNP
Power Dissipation Pd:65w
DC Collector Current:-5A
Collector Emitter Voltage V(br)ceo:-60V
DC Current Gain hFE:1000hFE
Transistor Case Style:TO-220
Minimum Operating Temperature:-65 °C
Operating Temperature Max:150°C
Dimensions:10.4 x 4.6 x 9.15mm
Package include:
20pcs*TIP125
