DSD TECH SH-RJ12C USB to RJ12 6P4C RS232 Serial Cable for APC PDU ATS(5.9FT/1.8M)

SH-RJ12C is the replacement of APC part 940-0144 and 940-0144A, used for APC switched or metered PDU unit.When your APC PDU or ATS needs to be debugged or configured, you can use this USB to RJ12 Serial Cable to communicate with it. Compatible for most of APC PDU units that have a RJ12 port like APC metered and switched PDU AP78xx, AP79xx, AP86xx, AP88xx, AP89xx, and etc.

Specification:
Model:SH-RJ12C
Main chip:PL2303GT
Pin Definition: Gnd,Tx,Rx,Gnd
Communication Protocol: RS232
Connectors: USB Type A, RJ12/RJ11 (6P4C)
The Maximum Speed: 1 Mbps
Cable Lenght: 1.8M/5.9 FT
Plug & Play after one time driver installation;

Precautions:
Although this data cable can transmit RS232 signals, it may not be compatible with your device. Because the line sequence of this data line is: NULL, Gnd, Tx, Rx, GND, NULL (please refer to the picture)
Different devices have different requirements for compatible data lines. You can adjust it manually or contact us for customization.

Applicable Equipment:
APC Automatic Transfer Switch:
AP7721, AP7723, AP7730, AP7732, AP7752
APC Rack PDU:
P78xx, AP79xx, AP86xx, AP88xx, AP89xx
Metered-by-Outlet with Switching Rack PDU:
AP8632, AP8641, AP8653, AP8659, AP8659EU3, AP8659NA3, AP8661, AP8681
Metered Rack PDU:
AP7152, AP7155, AP7175,AP7800, AP7801, AP7802, AP7802J, AP7811, AP7820
Metered-by-Outlet Rack PDU:
AP8441, AP8453,AP8459EU3, AP8459NA3, AP8459WW, AP8461, SPD10K
Switched Rack PDU:
AP7900, AP7901, AP7902, AP7902J, AP8930J, AP8931, AP8932, AP8930

List of supported systems:
1,Windows 7,8,10,11
2, various Linux OS and Mac OS

Packing list:
1 X SH-RJ12C USB to RJ12/RJ11 Serial Cable(5.9 Feet)
1 X User Manual

Customer Support:
DSD TECH offers a 1-year Replacement service and lifetime technical support for this USB to RJ12/RJ11 Serial Console Cable.If you meet any questions, Please contact us, We will fix your issue within 24 hours.
