U-508 Sonic Belt Tension Meter Tester Digital Belt Tension Gauge for Belt Tension Testing | Belt Tension Range 0.01N～99900N | Frequency Range 10.0Hz～5000Hz
$745.00
- Display and Measuring Range: Display range from 0.1 g/mm×m to 999.9 g/mm×m; measuring range from 10.0 Hz to 5000 Hz, 0.01 to 99900 N
- Measuring Accuracy: +/- 1%; Double display possible (Newton and/or Hz); Auto shutdown after 5 min. of inactivity
- Digital LCD display with backlit; Storage 40 sets belts data
- Application: Heavy Duty Equipment, Fans + Pumps, Conveyor Systems, Industrial Machines ,Compressors, Centrifuges, Bottling Machines, HVAC, Truck & Bus, Steel Mill (Cold/Hot), Dough MixerMedical CT& MRI, Motorcycle, Car, Bicycle, Industrial robot, Crusher, Printer, Cosmetic filling machine, Vacuum cleaners, Washing machines, Injection molding machines etc.
- Unlike the force-deflection method, which requires applying force to the belt, the U-508 Sonic Tension Meter measures belt tension by analyzing the harmonic properties of the belt’s vibration. Similar to strings, belts vibrate at a natural frequency determined by their mass and span length.
This product is fulfilled by seller
Sonic Belt Tension Meter U-508 SANKER Belt Tension Tester Tensiometer with Frequency Range 10Hz to 5000Hz Tension Range 0.01 to 99900N
Do you need to establish a specific drive belt tension foryour machine applications? Then reach for the belt tension meter U-508 and detemmine the degree of loads and tension of your belt installations immediately and with utmost precision.
Applicable to a V-belt, a multi ribbed beltor a synchronous belt the device analyses sound waves from the belt through the sensor and delivers you the accurate tension measurement without delay which is essential for the optimum perfomance and reliability of your belt drives.
U-508 ensures a smooth user experience including an easier reading of data thanks to its high definition LED display. The device is compact convenient to use and precise.
Specifications
Model Number: U-508
Test Tension Value: 0.01-99900N
Frequency Range: 10-5000Hz
Accuracy: 1%
Data Storage: 500 Groups
Power Supply: 2*AAA Batteries (not included)
Net Weight (Main Unit): 120g
Size: 59*26*160mm
Data Interface: Micro USB
Probe Size: 12.5*170mm (dia*Length)
Package Includes
1 x U-508 sonic belt tension meter
1 x Standard probe
1 x Percussion hammer
1 x Manual
Do you need to establish a specific drive belt tension foryour machine applications? Then reach for the belt tension meter U-508 and detemmine the degree of loads and tension of your belt installations immediately and with utmost precision.
Applicable to a V-belt, a multi ribbed beltor a synchronous belt the device analyses sound waves from the belt through the sensor and delivers you the accurate tension measurement without delay which is essential for the optimum perfomance and reliability of your belt drives.
U-508 ensures a smooth user experience including an easier reading of data thanks to its high definition LED display. The device is compact convenient to use and precise.
Specifications
Model Number: U-508
Test Tension Value: 0.01-99900N
Frequency Range: 10-5000Hz
Accuracy: 1%
Data Storage: 500 Groups
Power Supply: 2*AAA Batteries (not included)
Net Weight (Main Unit): 120g
Size: 59*26*160mm
Data Interface: Micro USB
Probe Size: 12.5*170mm (dia*Length)
Package Includes
1 x U-508 sonic belt tension meter
1 x Standard probe
1 x Percussion hammer
1 x Manual
| Brand Name | HKNDT |
|---|---|
| Part Number | U508NDT |
| Battery Cell Composition | Alkaline |
| Battery Type | AAA |
| Number of Batteries | 2 |
