Geloo 0-190ohm Marine Fuel Tank Sender - 22" (550mm) Boat Fuel Level Sending Unit with Water Level Sensor
$52.99
- SUPERIOR QUALITY: 22"(550mm) Fule Tank Sending Unit is Made SUS316 Stainless Steel and is a Standard SAE 5-hole type.It is the Direct Replacement for Arm Type sender. The advantages of fuel level sensor are accurate measurement, long service life, good shock resistance and corrosion resistance,keep you safe
- WIDE APPLICATION: 0-190ohm Water tank sender is suitable for automobiles, ships, speedboats, engines, generator sets, engineering machinery, agricultural machinery, modified vehicles and other fields, and without limitation of environment
- MULTIPLE SIZES: The length range is 150MM, 175MM, 200MM, 225MM, etc.Output signal: 0-190ohm.(0 ohms at empty, 190 ohms at full).Support 0-190ohm Fuel Level Gauge and Water Level Gauge (Please choose one length range & signal you need when placing the order)
- EASY INSTALLATION: The water level gauge sensor is a Standard SAE 5-hole type, Easy to install and connect.Blue wire is connected to ground (-), Brown wire is connected to the gauge signal wire.Operational Temperature: -40°C -+85°C. Stable output signal, universal style, suitable for all kinds of material tanks
- PACKAGE INCLUDES: 1X Fuel sending unit, Comes with 2mm thick gasket and 5 pieces of M5 mounting screws. Every products needs to go through strict quality inspection before leaving the factory, if you have any questions about the product, please let us know
This product is fulfilled by seller
Product Specifications: Material: SUS316 stainless steel Mounting Methods: Standard SAE 5 hole pattern Mounting: 5 pieces of M5 screws and 2 mm thick gasket Rated current for alarm switch: 500mA Output signal: 0-190ohm Resolution range: 21mm Operating temperatures: - 40 to 85°C Protection rank: IP67 Length range: 200MM; 300MM ; 350MM; 450MM; 500MM 600mm Output signal: 0-190ohm or 230-33ohm (Please choose one signal you need when placing the order ) Packing List 1* Level Sensor
| Brand Name | Geloo |
|---|---|
| Part Number | Level Gauge Sensor 600mm 0-190 ohm |
