1pc TPM-04SH Energy Analyzer Multimeter 3P&4W(3CT 100A)

Voltmeter
Features
Measures up to voltage harmonics 31st.
Measures up to current harmonics 31st.
Supports 3P4W connections.
RS485 Modbus RTU
71.5 × 61.5 Custom Design Glass
It shows the powers of each phase (P1, P2,
P3).
It shows the reactive powers of each phase
(Q1, Q2, Q3 inductive and capacitive).
It shows the apparent powers of each phase
(S1, S2, S3).
It shows power factors (PF) and cos values
of each phases.
It shows the min., max. and ave. values of the
phase-to-phase and phase-neutral voltages.
It shows the values of each phase (I1, I2,
I3).
It shows total import and export active
(kWh) energy.
It shows total inductive and capacitive
reactive (kVArh) energy.
Digital Input.
Relay output (adjustable).
It shows voltage and current irregularity.
It show demands.
You can delete energies and demands.
The menu is password protected.
Construction
1 - Indicates the unit of the value.
2 - Indicates which phase the value belongs to.
3 - Indicates displayed values. V=voltage, I=current,
F=frequency, S=apparent power, P=active power,
PF=power factor, Fl=cosine phi, THD-l=total
current harmonics, THD-V= total voltage
harmonics. Q=reactive power.
+P: Specified that the indicated active
energies are imported.
-P: Specified that the indicated active energies
are exported.
+Q: Specified that the indicated reactive
energies are inductive.
-Q: Specified that the indicated reactive
energies are capacitive.
§: Specified that the indicated reactive energies are inductive.
: Specified that the indicated reactive power are capacitive.
Min: Indicates that the values shown are
minimum.
Max: Indicates that the values shown are
maximum.
Ave: Indicates that the values shown are
average.
Dmd: Indicates that the values shown are
demand.
Din1: There is
