ATU-130 1.8‑50MHz 200W Micro Shortwave Automatic Antenna Tuner Mini Antenna Tuner with Metal Housing
$146.29
- ALUMINUM ALLOY: The shell of the antenna tuner is made of aluminum alloy, with light weight, fast heat dissipation and resistance.
- EXCELLENT PARTS: Adopts C channel 1000V high voltage SMD capacitor, advanced chip and UHF connector to ensure stable performance.
- GOOD PERFORMANCE: Higher level capacitance, larger magnetic , thicker wire diameter, greater power bearing capacity, total inductance 12.4uh.
- COMPACT SIZE: The automatic antenna tuner has compact structure, convenient connection, portable design is suitable for home or vehicle use.
- ANTENNA TUNER: Miniature shortwave automatic antenna tuner, without any control line operation, suitable for most radio stations.
This product is fulfilled by seller
Spec:
Item Type: Automatic Antenna Tuner
Model: ATU-130
Material: Aluminum Alloy
Power Supply Voltage Range: 10-15VDC (+in the center)
Maximum Current Consumption: 500mA
Maximum Working Power: 150W
Starting Tuning Minimum Power: 5W
Minimum Measurable Power: 0.1W
Measurement Accuracy Up to 10W Power: 0.1W
Measurement Accuracy Greater Than 10W Power: 1W
Maximum Installed Inductance: 8.53?H
Minimum Installation Inductancee: 0.05?H
Micro Automatic Antenna Tuner Features:
Has the function of power meter standing meter (according to BYPASS, straight through mode, one horizontal line in the middle of the screen, the test value is approximate, and the accuracy is lower than that of professional high accuracy meter, for reference).
PIC18F2520, MCU (faster).
Short machine automatic antenna tuner
The third edition adopts the design of 4 large magnetic ring inductors, which generates less heat than the original edition.
HF32, 10A, HF33, 5A relays are used.
High voltage porcelain chip capacitor is adopted.
The maximum measurable value is SSB 275w. It is recommended that the SSB should not exceed 200w for a long time.
For other continuous modes, the power shall not be greater than 100W (FT8, CW, FM, when the standing deviation is large before adjustment, the power shall be reduced as appropriate, and it is recommended to use 10min interval for 5min).
Size: Approx. 38 x 88 x 155mm / 1.5 x 3.5 x 6.1in (excluding projections)
Weight: Approx. 0.5Kg / 17.6oz (portable, suitable for vehicle, indoor and outdoor fixation, etc.)
1.8-50MHz (specifically affected by antenna length and standing deviation).
Tuning Impedance Range: 5?-1.2K?
Application: Can be used for long line (recommended), GP (recommended), inverted V, bipolar, end fed and other antennas to adjust standing and match short machine impedance.
Package List:
1 x Antenna
Item Type: Automatic Antenna Tuner
Model: ATU-130
Material: Aluminum Alloy
Power Supply Voltage Range: 10-15VDC (+in the center)
Maximum Current Consumption: 500mA
Maximum Working Power: 150W
Starting Tuning Minimum Power: 5W
Minimum Measurable Power: 0.1W
Measurement Accuracy Up to 10W Power: 0.1W
Measurement Accuracy Greater Than 10W Power: 1W
Maximum Installed Inductance: 8.53?H
Minimum Installation Inductancee: 0.05?H
Micro Automatic Antenna Tuner Features:
Has the function of power meter standing meter (according to BYPASS, straight through mode, one horizontal line in the middle of the screen, the test value is approximate, and the accuracy is lower than that of professional high accuracy meter, for reference).
PIC18F2520, MCU (faster).
Short machine automatic antenna tuner
The third edition adopts the design of 4 large magnetic ring inductors, which generates less heat than the original edition.
HF32, 10A, HF33, 5A relays are used.
High voltage porcelain chip capacitor is adopted.
The maximum measurable value is SSB 275w. It is recommended that the SSB should not exceed 200w for a long time.
For other continuous modes, the power shall not be greater than 100W (FT8, CW, FM, when the standing deviation is large before adjustment, the power shall be reduced as appropriate, and it is recommended to use 10min interval for 5min).
Size: Approx. 38 x 88 x 155mm / 1.5 x 3.5 x 6.1in (excluding projections)
Weight: Approx. 0.5Kg / 17.6oz (portable, suitable for vehicle, indoor and outdoor fixation, etc.)
1.8-50MHz (specifically affected by antenna length and standing deviation).
Tuning Impedance Range: 5?-1.2K?
Application: Can be used for long line (recommended), GP (recommended), inverted V, bipolar, end fed and other antennas to adjust standing and match short machine impedance.
Package List:
1 x Antenna
| Brand Name | Walfront |
|---|---|
| Part Number | WALFRONTggrviqope2 |
| Impedance Unit | Ohm |
| Impedance | 500.000000 |
