PF10000359965
In stock
Gebildet JD2912 Car Relay with 12AWG Harness Sockets 24V 40A 4 Pin SPST with Color-Labeled Wires for Automotive Truck Van Motorcycle Boat (Pack of 2)
$9.99
- Brand new heavy duty SPST (Single Pole Single Throw) relays with color-labeled wires
- Rated operational voltage: 24V/ Switching Capability: 40A
- Standard operating voltage 24V, corresponding standard operating current is 70mA. Minimum operating voltage 16V, corresponding minimum operating current is 50mA.
- Small size/Low power consumption/High contact voltage/ High sensitivity
- Contact Material: Ag Alloy / Contact Resistance: ≤ 100MΩ. Life Expectancy Electrical: 100,000 Operation, Life Expectancy Mechanical: 10,000,000 Operation.
This product is fulfilled by seller
Interchangeable/Compatible with:
All automobiles and devices equipped with a 24 Volt DC power source.
Relay technical specification:
Relay load: 40A/24VDC
Contact Resistance: ≤ 100MΩ
Contact Material: Ag Alloy
Life Expectancy Electrical: 100,000 Operations (at 30 Operations/min)
Life Expectancy Mechanical: 10,000,000 Operations
Coil power: 1.8W
Operate Time: 15ms
Release Time: 10ms
Initial withstand voltage of Contact and Contact: 1000VAC/1min
Initial withstand voltage of Contact and Coil: 1500VAC/1min
Insulation Resistance: 100MΩ/( 500VDC)
Temperature Range: -55°C ~+70°C
Humidity Range:35%-80%
Atmospheric Pressure:86-106KPa
Operation Goal:
Create value for our customers is our responsibility, quality products and sincere service is our eternal pursuit.
After Sales Service:
Customer satisfaction is our greatest pursuit, If you found our products don’t work or not so good quality as you think, Please contact us without hesitation.
All automobiles and devices equipped with a 24 Volt DC power source.
Relay technical specification:
Relay load: 40A/24VDC
Contact Resistance: ≤ 100MΩ
Contact Material: Ag Alloy
Life Expectancy Electrical: 100,000 Operations (at 30 Operations/min)
Life Expectancy Mechanical: 10,000,000 Operations
Coil power: 1.8W
Operate Time: 15ms
Release Time: 10ms
Initial withstand voltage of Contact and Contact: 1000VAC/1min
Initial withstand voltage of Contact and Coil: 1500VAC/1min
Insulation Resistance: 100MΩ/( 500VDC)
Temperature Range: -55°C ~+70°C
Humidity Range:35%-80%
Atmospheric Pressure:86-106KPa
Operation Goal:
Create value for our customers is our responsibility, quality products and sincere service is our eternal pursuit.
After Sales Service:
Customer satisfaction is our greatest pursuit, If you found our products don’t work or not so good quality as you think, Please contact us without hesitation.
| Brand Name | Gebildet |
|---|---|
| Part Number | E195 |
| Wattage | 1.800000 |
| Wattage Unit | Watts |
| Current Rating Unit | Amps |
| Current Rating | 40.000000 |
| Upper Temperature Rating | 70.000000 |
| Maximum Switching Current Unit | Amps |
| Maximum Switching Current | 40.000000 |
| Coil Voltage | 24.000000 |
| Coil Voltage Unit | Volts |
| Contact Current Rating Unit | Amps |
| Contact Current Rating | 40.000000 |
| Minimum Switching Voltage | 16.000000 |
| Minimum Switching Voltage Unit | Volts |
| Release Time | 0.010000 |
| Release Time Unit | Seconds |
