PF10000358003
In stock
Groza SDI to HDMI Converter, 3G SDI to HDMI Audio Video Adapter, Support SD-SDI, HD-SDI and 3G-SDI Signals for Camera Detector
$39.99
- The SDI to HDMI converter allows SD-SDI, HD-SDI and 3G-SDI signals to be shown on HDMI displays while ensuring high bit rates of 2.970 Gbit/ s to give you fast signal transmission without any loss.
- Support separate and convert the audio signal in the SDI signal then embed it into HDMI signal to achieve long distance synchronous transmission of sound and imag.
- Support SDI resolution: 3G-SDI: 1080@60/50Hz; HD-SDI: 1080i@60/50Hz, 720P@60/50Hz. Does not support SD-SDI signal (480i and 576i).
- Support the operates rate of 2.970 Gbit/ s, 1.485 Gbit/ s and 270 Mbits/ s, can convert non-standard SDI signal to standard HDMI 720P/ 1080P signal output to adapt to different monitor.
- What You Get: SDI to HDMI Converter x 1; 5V/ 1A DC Power Supply Adaptor x 1; User manual x 1.
This product is fulfilled by seller
SDI to HDMI Converter, 3G SDI to HDMI Audio Video Adapter, Support SD-SDI, HD-SDI and 3G-SDI Signals for Camera Detector This SDI to HDMI converter allows SD-SDI, HD-SDI and 3G-SDI signals to be shown on HDMI displays while ensuring high bit rates of 2.970 Gbit/ s to give you fast signal transmission without any loss. It can also separate and convert the audio signal in the SDI signal then embed it into HDMI signal to achieve long distance synchronous transmission of sound and images. Specifications Input Port: 1 x BNC (SDI/ HD-SDI/ 3G-SDI) Output Port: 1 x HDMI Power Supply DC 5V / 1A Dimension: 95mm x 43mm x 23mm Features Supports resolution of the automatic recognition. Support full HD 1080P@60Hz output. Audio and image output synchronously. Suitable for HD monitoring field. Supported SDI formats: SD-SDI (SMPTE 259M, up to 270Mbps); HD-SDI (SMPTE 292M, 296M, up to 1.485Gbps); 3G-SDI (SMPTE 424M, 425M level A, B, up to 2.97Gbps). Features automatic detection of 3G/ HD/ SD-SDI signals. Plug and play, easy to install. Package 1 x SDI to HDMI Converter 1 x 5V / 1A DC Power Supply Adaptor 1 x User Manual
| Brand Name | Groza |
|---|---|
| Part Number | 00001 |
| Current Rating Unit | Amps |
| Current Rating | 1.000000 |
| Input Voltage Unit | Volts |
| Input Voltage | 5.000000 |
| Nominal Power Unit | Watts |
| Nominal Power | 5.000000 |
| Cable Length Decimal Value | 0.000000 |
| Cable Length Unit | Meters |
