10T Hydraulic Hand Pump 10000Psi Separated Type Manual Hydraulic Ram Pump Kit with Non-Slip Handle Steel Balls and Sealing Ring Suitable for Using Varieties of Hydraulic Tools
- ★【Durable Material】-- The item is made of steel, which is relatively strong and stable. It is also not easy to damage or rust under proper use and is very durable.
- ★【Large Reservoir Capacity】-- The large oil storage capacity of 400cc allows you to use it easily without frequent refueling.
- ★【User-friendly】--The manual hydraulic pump has a long ergonomic operating handle for a smoother, more comfortable grip during use. Its thickened insulation feature also provides non-slip hand protection for long-term use.
- ★【Strong Power】-- Under the condition of constant power, low pressure and large flow oil supply and high pressure and small flow oil supply can save time and improve efficiency. Its 10000Psi maximum output pressure and 10T safety load also promote its work efficiency.
- ★【Wide Use】-- The pump can be used together with other hydraulic tools, such as a hydraulic jack, hydraulic crimping machine, hydraulic punching machine, hydraulic pipe bender, etc.
Features
Wide Application: It can be used with most split hydraulic equipment with a ZG3/8'' threaded interface.
Integrated Structure: The product with an integrated structure can be directly used with jacks without an additional installation.
Details
Oil Return Switch: The rotary oil return switch is easy to use, and the clear identification on it can make your operation more accurate.
Bifurcated Base: The base with a bifurcated shape has stronger stability.
How to Use
1. First, connect the connector of the manual pump to the jack.
2. Select the position and tighten the drain screw of the hydraulic pump to work.
Specification
Model: CP-180
Material: Alloy Steel
Color: Yellow
Safe Load: 10T/22046.23lbs
Thread Connection: ZG3/8''
Maximum Output Pressure: 10000Psi
High Pressure Output: 700KG/CM²
Low Pressure Output: 60KG/CM²
Oil Storage: 400cc/24.41cu in
Tubing Length: 1M/39.37in
Handle Length: About 34cm/13.39in
Gross Weight: 4kg/ 8.82 lbs
Net Weight: 3.3kg/ 7.28 lbs
Product Size: 33*11*11cm/12.99*4.33*4.33in
Package Size: 17*22*38cm/6.69*8.66*14.96in
Package Included
1 * Manual Hydraulic Pump
1 * Steel Ball
1 * Sealing Ring
| Brand Name | Eapmic |
|---|---|
| Part Number | 00001 |
