HEQIM 30 Ton Hydraulic Ram Jack + 10000psi Cp-180 Hand Pump, Stroke 14mm and ZG3/8 Thread, Low Profile Hydraulic Cylinder Ram Jack Kit for Machinery Shipbuilding(with Pump)
$302.24
- Ultra-thin & Portable Hydraulic Jack Kit The hydraulic cylinder tonnage: 30 Tons. Lifting stroke: 14mm/0.55inch. Body height: 60mm/2.36in. Exended height: 74mm/2.9in. Suitable for lifting and supporting work in narrow spaces.
- Hydraulic Hand Pump Parameters: Oil pipe coupling with: ZG3/8 thread, Hose : 1m., Oil capacity: 350cc, High pressure output: 700kg/cm², Length: 330mm. Suitable for 5T/10T/20T/30T hydraulic jacks
- High Quality Cylinder: Our hydraulic cylinder jack is made of heavy-duty metal construction, durable and designed for long-lasting use. Paint spraying at the surface, prevent scratching and corrosion.
- Automatically Retract: This hydraulic ram cylinder can automatically retract to the initial height after the oil return valve of the pump is loosened, which is easy and convenient to operate.
- Wide Application: This hydraulic manual pump and hydraulic jack set is used for equipment installation and jacking in construction, electrical engineering, machinery manufacturing, mining, textile, shipbuilding and other industries
This product is fulfilled by seller
Wide ApplicationsHydraulic jacks can be widely used in electric power, chemical industry, steel, bridge, shipbuilding, machinery and other industries. Hydraulic cylinders are not suitable for use in cars. Equipped with various accessories, it has multiple functions such as lifting, jacking, shoveling, splitting, etc., and can be quickly installed with quick connectors.
Easy to CarryThe hydraulic hand pump is small in size, which is especially beneficial in narrow spaces. It offers portability and flexibility while delivering massive lift.
Product parameters:
CP-180 manual hydraulic pump:
High pressure: 700kg/cm²
Oil storage capacity: 350cc
Weight: about 5.2kg
30T Hydraulic jack Cylinder:
Stroke: 14mm
Body height: 60mm/2.36in
Exended height: 74mm/2.9in
Weight: 5kg
Note: The hydraulic jack is suitable for vertical, horizontal and inverted orientations, but not for inclined use. Requires attachment to a firm, flat lifting surface, not a soft or rough surface
Easy to CarryThe hydraulic hand pump is small in size, which is especially beneficial in narrow spaces. It offers portability and flexibility while delivering massive lift.
Product parameters:
CP-180 manual hydraulic pump:
High pressure: 700kg/cm²
Oil storage capacity: 350cc
Weight: about 5.2kg
30T Hydraulic jack Cylinder:
Stroke: 14mm
Body height: 60mm/2.36in
Exended height: 74mm/2.9in
Weight: 5kg
Note: The hydraulic jack is suitable for vertical, horizontal and inverted orientations, but not for inclined use. Requires attachment to a firm, flat lifting surface, not a soft or rough surface
| Brand Name | HEQIM |
|---|---|
| Part Number | HEQIM |
