RustyVioum 20 Ton Hydraulic Ram Cylinder Jack Porta Power Ram, Manual Hydraulic Pump 50mm/ 1.97in Jack Stroke, Portable Mini Single Acting Lifting Cylinders for Hydraulic Punches Hydraulic Cutting
- 【Durable material】The 20t hydraulic cylinderis made of steel, which is relatively strong and stable. It is also not easy to damage or rust under proper use and is very durable. Its proper size and weight (7kg/ 15.43lbs) allow it to follow you through various operations.
- 【Strong power】The maximum working pressure of the hydraulic pump can reach 70Mpa, a reservoir capacity of 350cc, which is more powerful than other similar machines and more convenient to use. And its jack has a tonnage of 20T/ 44092lbs, providing you with stronger power. It not only has a smooth surface, but also has good sealing and no oil leakage.
- 【Easy to operate】Its structure is not complicated and does not require complicated installation and operation steps, so you can easily master it. As it is manual, it can continue to work without electricity, so it is very convenient to use.
- 【User-friendly】The manual hydraulic pump has a long ergonomic operating handle for a smoother, more comfortable grip during use. Its thickened insulation feature also provides non-slip hand protection for long-term use.
- 【Wide application】The hydraulic ram cylinder jack can be used with hydraulic punches, hydraulic cutting machines, hydraulic cylinders, hydraulic tongs, etc. to perform various operations, such as lifting, bending, straightening, shearing, riveting, assembly, disassembly, etc.
Specifications
Name: Manual Hydraulic Pump
Model: BSC-20 + CP-180
Color: Orange
Material: Steel
Surface Treatment: Plastic Spraying
Condition: Brand New
Type: Manual
Oil Reserves: 350CC
Maximum Pressure: 70Mpa（700kg/ cm²）
Low-Pressure Speed: 2L/ s (0.44Gal/ s)
High-Pressure Speed: 0.2L/ s (0.044Gal/ s)
Tubing Connector: ZG3/8''
Jack Tonnage: 20T/ 44092lbs
Jack Spindle Diameter: 50mm/ 1.97in
Jack Stroke: 50mm/ 1.97in
Jack Extension Height: 155mm/ 6.1in
Pump Body Length: 33cm/ 13in
Pump Body Height: 11cm/ 4.3in
Handle Length: 34cm/ 13.4in
Tube Length: 1m/ 3.3ft
Lifting Jack Size: 8.8*10.5cm/ 3.46*4.13in
Package Size: 37.5*22.5*16cm/ 14.76*8.86*6.3in
Net Weight: 7kg/ 15.43lbs
Gross Weight: 8.5kg/ 18.74lbs
Package Included
1* Manual Hydraulic Pump
1* Lifting Jack
1* 1m Hose
1* Handle
Notes
1. Please note that there is a pressure-reducing valve on the cylinder head, which should be loosened during use to avoid sealing the hydraulic cylinder.
2. Please note that the bearing surface needs to be hard and flat.
3. When using, please do not bias the load, and stop the operation immediately when you see the stop line.
4. Please allow the slight color difference caused by the shooting light and 1-3 cm error due to manual measurement, and make sure you do not mind before ordering.
| Brand Name | RustyVioum |
|---|---|
| Part Number | hydraulic cylinders |
| Load Capacity | 20 |
| Regulatory Identification | NSDOS.0384EM-005 |
