DTECH 3ft USB to TTL Serial Cable 5V 6 Pin UART Adapter Debug Cord Compatible with Windows 11 10 8 7 Linux MAC OS Genuine FT232RL Chip 6Pin 5 V Level Signal 2.54mm Dupont Female Header

3-Foot USB TTL serial adapter built with FT232RL chip for 5V logic level serial communication (rx, tx and GND)
It is built with FT232r chip that its royalty-free VCP driver allow for communication as a standard COM port and D2XX ‘direct’ drivers provide DLL application programming interface; a great conversion data cord to meet with your needs of debugging, boot-loading, programming, etc.

The original FT232 chip is embedded in the USB-A end; 6 way 0.1” header connector with VCC (5V power) and GND (ground), as well as RXD, TXD, RTS and CTS at 5V logic level.

Applications:
Upgrading Legacy Peripherals to USB
Interface Microcontroller UART or I/O, FPGA / PLD to USB
As a switching device in driving lamps and relays
Replace MAX232 type level shifters allowing for direct connection of products to PC
Used in processors of mini computers like DEC VAX
Industrial Control, USB Software, Hardware Encryption Dongle, printer, video display terminals, Oscilloscope, measurement device, microprocessor, light and remote controller, etc.

USB to uart wire, entire USB protocol handled by the electronics in the cable;
UART interface support for 7 or 8 data bits, 1 or 2 stop bits and odd / even / mark / space / no parity;
Data transfer rates from 300 to 3M baud rate at TTL levels;
Internal EEPROM with users writable area; Supply voltage comes from USB bus, no external supply required;
UHCI / OHCI / EHCI host controller compatible

Interfaces: USB 2.0 type A Male Port ; 6 pin Female Socket header
Supports Windows 2008, XP, Vista , CE 4.2, 5.0 and 6.0, Windows 11, 7, 8, 8.1, 10; Mac, Linux
NOTE: If any installation or usage issues, please email us or you may download a driver and usage guide on FT232 chip official website

What’s Included
1x Type A male USB to Serial TTL Level Converter Cable 3 ft
1x Manual
