Dicio Winged Wire Connectors Twist 100 PCs UL Listed, Electrical Connectors Screw-On Gray Wire Terminals for Connect Electrical Wiring,Low Voltage Grey Wire Caps for 18-8 AWG
- Superior Electrical Insulation: Dicio winged wire connectors feature a flame retardant thermoplastic shell that provides exceptional electrical insulation. This ensures safety and reliability in your electrical connections, giving you peace of mind.
- Easy Tool-Free Installation: Dicio electrical wire caps feature built-in, swept-back designed wings that allow for easy tightening without the need for any tools. This simplified installation process saves you time and effort.
- High current carrying capacity: The twist connector boast outstanding current conductivity, enabling them to withstand high current loads and effectively protect electrical equipment and systems.
- Versatile applications: low voltage wire connector is suitable for various electrical connection needs. They can be used for household wire connections, lighting fixtures, electrical equipment, and other low voltage applications. Whether it's for daily life or professional work, they are an ideal choice.
- Reliable Wing Connectors Nut: Dicio winged wire connectors are specifically designed to provide a secure and enduring connection. The wing connectors nut design allows for easy installation and removal, ensuring convenient and hassle-free wire connections.
Dicio aims to make home electricity safer and easier by providing top-notch wire connectors to our users worldwide.
Dicio manufacturers have been in business for over 30 years, offering wire connectors suitable for home electricity work and home appliances.
How to Use the Dicio P15 Gray Winged Wire Connectors
1) Ensure the power is turned off before installing or removing connectors.
2) Strip the wires to a length of 3/4" (19.1 mm).
3) There's no need to pre-twist. Hold the stripped wires together with the ends even. Allow stranded wires to lead slightly.
4) Align any frayed strands or conductors. Push the wires into the connector and screw on until two twists are visible in the wires.
Product Specification
- Dimension : 33.3 mm / 1.31 in. height
- Terminates 18-8 AWG wire
- Operating Voltage: 600V
| Brand Name | dicio |
|---|---|
| Part Number | PH |
| Gauge Decimal Value | 1.000000 |
| Maximum Voltage Unit | Volts |
| Maximum Voltage | 600.000000 |
| Operating Voltage Unit | Volts |
| Operating Voltage | 450.000000 |
| Item Height Unit | Inches |
| Item Height base to top | 1.000000 |
| Item Length Unit | Inches |
| Item Length Longer Edge | 1.000000 |
| Item Width Unit | Inches |
| Item Width Shorter Edge | 1.000000 |
