2-4-6 Blocks Matched Pair with 23 Holes Precision Machinist Milling Accuracy 0.0003In (2-Pack)
$81.99
- 2In x 4In x 6In, 17 lbs. Weight
- Made of hardened tool steel and precision ground on all six sides
- 0.0003 height accuracy precision matched blocks for mounting work for precision
- Precision steel blocks Has 23 holes with 5 holes tap to 3/8-16 threads for clamping and 18 untapped holes
- This steel blocks can be used for set-up, layout and inspection jobs. Suitable for all kinds of machine tool
This product is fulfilled by seller
2-4-6 Blocks Matched Pair
Specification:
Size within +/- 0.0003"
Flatness and parallelism within 0.0003"
Squareness on all sides is 0.0003" per inch
Pairs are matched to a tolerance of 0.0003"
Feature:
Heat treated and case hardened to HRC 57-62
Accuracy and squareness on all sides within 0.0003"
23 holes includes (5) 3/8-16 threaded holes for clamping and (18) untapped holes
Cross drilling design allows for efficient use of lower weight with maximum strength
Applications:
Used for set-up, layout and inspection jobs
Be used outside a vise utilizing the pre-drilled holes, their applications are expanded by bolting them together
Package includes
2 x 2-4-6 Block
Specification:
Size within +/- 0.0003"
Flatness and parallelism within 0.0003"
Squareness on all sides is 0.0003" per inch
Pairs are matched to a tolerance of 0.0003"
Feature:
Heat treated and case hardened to HRC 57-62
Accuracy and squareness on all sides within 0.0003"
23 holes includes (5) 3/8-16 threaded holes for clamping and (18) untapped holes
Cross drilling design allows for efficient use of lower weight with maximum strength
Applications:
Used for set-up, layout and inspection jobs
Be used outside a vise utilizing the pre-drilled holes, their applications are expanded by bolting them together
Package includes
2 x 2-4-6 Block
| Brand Name | raseparter |
|---|---|
| Part Number | Does not apply |
